Assembly Instructions
DINING CHAIR
Description
Right Front Leg
(Labelled 'A')
Left Front Leg
(Labelled 'B')
Left Back Leg
(Labelled 'C')
Right Back Leg
(Labelled 'D')
Backrest
Seat
QTY
1
1
1
1
1
1
Page 1 of 6
