- Page 1 Assembly Instructions Caution: You must read this before you proceed Dining Bench Part List Label Picture Description Backrest Noble house Home Furnishings LLC Page 1 OF 7...
- Page 2 Seat Front Leg (with Pre-installed Leveller) Back Leg (with Pre-installed Leveller) Middle Support Leg Hardware Label Picture Description ① Bolt (M6*28mm) ② Spring Washer ③ Washer (φ16) ④ Washer (φ19) Noble house Home Furnishings LLC Page 2 OF 7...
-
Page 3: Assembly Preparation
⑤ Allen Key Assembly Preparation Before Beginning Assembly: Assembly Steps Noble house Home Furnishings LLC Page 3 OF 7... - Page 4 This Dining Bench has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Dining Bench, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 2.1) Align Seat(B) to Backrest(A) as shown in above picture. 2.2) Attach Seat(B) to Backrest(A) using Bolts(①), Spring Washers(②) and Washers(④) with Allen Key(⑤) as shown in above picture. Tighten Bolts fully in a sequential manner. Step 3 Noble house Home Furnishings LLC Page 5 OF 7...
- Page 6 Tighten the Bolts fully in a sequential manner. Step 4 With assistance from your adult partner, adjust the Pre-installed Levellers at the bottom of Front Legs(C) and Back Legs(D) until the Dining Bench is level with the ground. Step 5 Your Dining Bench is ready for use.
- Page 7 Noble house Home Furnishings LLC Page 7 OF 7...
