Caution : You must read this before you proceed
CAUTION : This chair is NOT a TOY.
Keep your child / children at bay in the process of assembly.
Parts List
Label
A
B
C
D
Noble house Home Furnishings LLC
Assembly Instructions
Dining Chair
Description
Backrest Panel
Seat Panel
Left Arm Leg with Pre-
attached
Levellers
Right Arm Leg with
Pre-attached
Levellers
QTY
1
1
1
1
Page 1 OF 6
Advertisement
Related Manuals for Noble House Home Furnishings Dining Chair
Summary of Contents for Noble House Home Furnishings Dining Chair
- Page 1 Keep your child / children at bay in the process of assembly. Parts List Label Picture Description Backrest Panel Seat Panel Left Arm Leg with Pre- attached Levellers Right Arm Leg with Pre-attached Levellers Noble house Home Furnishings LLC Page 1 OF 6...
-
Page 2: Assembly Preparation
Hardware Label Picture Description ① Bolt(M8*25mm) ② Bolt(M8*30mm) ③ Washer(8mm) ④ Spring Washer(8mm) ⑤ Plastics Cap(8mm) ⑥ Allen Wrench ⑦ Spanner Assembly Preparation Before Beginning Assembly: Noble house Home Furnishings LLC Page 2 OF 6... - Page 3 Please read through the instructions below to familiarise yourself with the parts and steps before assembly. Step 1 Unpack and place all parts on a clean soft surface. Noble house Home Furnishings LLC Page 3 OF 6...
- Page 4 Do not fully tighten at this stage. Step 3 Then attach Chair Seat Panel(B) to Left Arm Leg with Pre-attached Levellers(C) using Bolts(②), Spring Washers(④) and Washers(③) with Allen Wrench(⑥). Do not fully tighten at this stage. Noble house Home Furnishings LLC Page 4 OF 6...
- Page 5 Then Add Plastics Caps(⑤) on 4 bolt ends on the Backrest Panel of the chair to protect skin or clothing from getting snagged. Your Chair is ready for use. Caution: This Chair can only be used on a flat, level surface. Noble house Home Furnishings LLC Page 5 OF 6...
- Page 6 Noble house Home Furnishings LLC Page 6 OF 6...
