Caution : You must read this before you proceed
ROCKING CHAIR
Noble House Home Furnishings LLC
Page 1 OF 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROCKING CHAIR and is the answer not in the manual?

Questions and answers

Summary of Contents for Noble House Home Furnishings ROCKING CHAIR

  • Page 1 Caution : You must read this before you proceed ROCKING CHAIR Noble House Home Furnishings LLC Page 1 OF 9...
  • Page 2 Label Picture Description Left Arm Panel Right Arm Panel Back Seat Label Picture Description ① Bolt (M8*60MM) ② Bolt (M8*50MM) ③ Spring Washer ④ Washer(18MM) ⑤ Allen Key Noble House Home Furnishings LLC Page 2 OF 9...
  • Page 3 Before Beginning Assembly: Overview Back (C) Right Arm Panel (B) Seat (D) Left Arm Panel (A) Front Facing Noble House Home Furnishings LLC Page 3 OF 9...
  • Page 4 This Rocking Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Rocking Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
  • Page 5 Put the Chair back(C) onto table. Align the mounting positions of the Back(C) with Seat(D) and attach them using Bolts(①), Spring Washers(③) and Washers(④) with Allen Key(⑤). Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 5 OF 9...
  • Page 6 Note: If the mounting positions cannot be aligned well and hinder installation, then sway the Seat(D) lightly when locking the Bolts, this action should help prevent the Bolts from getting stuck and ensure smooth assembly. Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 6 OF 9...
  • Page 7 Do not fully tighten the Bolts. Repeat the same process with the Left Arm Panel(A) Repeat the same assembly process from Step 3 and Step 4 with the Left Arm Panel(A). Noble House Home Furnishings LLC Page 7 OF 9...
  • Page 8 Then smooth down the Dust Cover on the Seat bottom with your hands on all four edges. Step 6 Your Rocking Chair is ready for use. This Rocking Chair can only be used on a flat, level surface. Noble House Home Furnishings LLC Page 8 OF 9...
  • Page 9 Noble House Home Furnishings LLC Page 1 OF 1...
