Assembly Instructions
Caution: You must read this before you proceed.
Armless Chair
Caution: This Chair is NOT a TOY.
Keep your child/children at bay during the assembly process.
Whenever moving/lifting the Chair and to prevent damage to the Chair, two
adults are needed to execute these actions.
Noble House Home Furnishings LLC
1 of 11
Advertisement
Related Manuals for Noble House Home Furnishings Armless Chair
Summary of Contents for Noble House Home Furnishings Armless Chair
- Page 1 Caution: This Chair is NOT a TOY. Keep your child/children at bay during the assembly process. Whenever moving/lifting the Chair and to prevent damage to the Chair, two adults are needed to execute these actions. Noble House Home Furnishings LLC 1 of 11...
-
Page 2: Part List
(with Pre-installed Levellers) Seat Panel Back Support Bar Front Support Bar Seat Cushion Back Cushion Hardware Picture Description Bolt ① (M6x35mm) Screw ② (M6x55mm) ③ Allen Key Assembly Preparation Before Beginning Assembly: Noble House Home Furnishings LLC 2 of 11... - Page 3 Noble House Home Furnishings LLC 3 of 11...
-
Page 4: Assembly Steps
This Armless Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Armless Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly. - Page 5 Insert dowels on Back Support Bar(E) and Front Support Bar(F) into mountings on Left Panel(B). Attach Back Support Bar(E) and Front Support Bar(F) to Left Panel(B) using Bolts(①) with Allen Key(③). Do not fully tighten the Bolts. Noble House Home Furnishings LLC 5 of 11...
- Page 6 Step 3 Insert dowels on Backrest Panel(A) into mountings on Left Panel(B). Attach Left Panel(B) to Backrest Panel(A) using Bolts(①) with Allen Key(③). Do not fully tighten the Bolts. Noble House Home Furnishings LLC 6 of 11...
- Page 7 Right Panel(C) as pictured above Attach Right Panel(C) to Backrest Panel(A), Back Support Bar(E) and Front Support Bar(F) using Bolts(①) with Allen Key(③). Do not fully tighten the Bolts. Noble House Home Furnishings LLC 7 of 11...
- Page 8 Insert Seat Panel(D) onto Chair frame as shown above. Attach Seat Panel(D) to Right Panel(C) and Left Panel(B) using Screws(②) with Allen Key(②). Note: Insert Screws(②) from inside to outside of Seat Panel(D) Do not fully tighten the Screws. Noble House Home Furnishings LLC 8 of 11...
- Page 9 Adjust the Levellers until the Chair is level with the ground. To adjust the Levellers, get assistance from an adult partner to lift/lean and hold the Chair while you are working. Step 7 Noble House Home Furnishings LLC 9 of 11...
- Page 10 Chair as shown above. Your Armless Chair is ready to be used. This Armless Chair can only be used on a flat, level surface. Step 8 With assistance from your adult partners, place the Chairs facedown and connect the pre-attached clips to connect the Chairs together.
- Page 11 Noble House Home Furnishings LLC 11 of 11...
