- Page 1 Caution : You must read this before you proceed SOFA Noble House Home Furnishings LLC Page 1 OF 10...
- Page 2 Label Picture Description Backrest Left Armrest Right Armrest Seat Seat Cushion Sofa Leg Noble House Home Furnishings LLC Page 2 OF 10...
- Page 3 Label Picture Description ① Bolt (M8*70 MM) ② Washer ③ Gasket ④ Allen Key ⑤ Spring Washer Before Beginning Assembly: Noble House Home Furnishings LLC Page 3 OF 10...
- Page 4 Sofa Leg(F) FRONT FACING This Sofa has multiple parts and may require up to 60 minutes to assemble. To give you an overview of the Sofa, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 'slip and slide' assembly. Caution : Do exercise Caution to ensure that your fingers do not get caught or pinched in the assembly process. Noble House Home Furnishings LLC Page 5 OF 10...
- Page 6 Push the Seat(D) downwards until it is fully slotted and locked into position in the Armrests. Fully locked postion : Check and assess that the base of the Armrests(B&C) and Seat(D) are aligned and level. Assistance from an adult partner is needed for this assembly process. Noble House Home Furnishings LLC Page 6 OF 10...
- Page 7 Connectors on Left Armrest(B) and Right Armrest(C). Fully locked postion :Check and assess that the base of the Armrests(B&C) and Seat(D) are aligned and level. Assistance from an adult partner is needed for this assembly process. Noble House Home Furnishings LLC Page 7 OF 10...
- Page 8 Seat(D) Backrest(A) Left Armrest(B) Tilt and lay the Sofa on its Backrest(A) onto a flat surface. Attach Seat(D) to Backrest(A) using Bolts(①), Spring Washers(⑤), and Washers(②) with Allen Key(④) as pictured above firstly. Then, attach Seat(D) to Left Armrest(B) and Right Armrest(C) using Bolts(①), Spring Washers(⑤), and Washers(②) with Allen Key(④).
- Page 9 Sofa Leg(F) Test for stability Install the Sofa Leg(F) at the base of the Sofa by placing one Gasket(③) on the threaded stem. Then insert threaded stem into the threaded mounting postion at the corner of the Sofa. Tighten by turning the Leg clockwise.
- Page 10 Noble House Home Furnishings LLC Page 10 OF 10...
