Chapter 2 — Installation

Memory Cartridge

The EasyCoder PC41 is fitted with 2MB of built-in EPROM and 512K
DRAM. The built-in memory can be expanded using an exchangeable
memory cartridge with 1MB Flash memory.
When fitting or removing a memory cartridge, the power to
the printer must be off!

Installation of Memory Cartridge

Ensure that the On/Off switch on the printer is off (0).
1
Open the top cover by pressing the two locks on either side.
2
Remove the cartridge slot cover located to the left of the media roll.
3
Be careful not to drop it inside the printer.
Ensure that the switch at the front short side of the cartridge is in its
4
lower position.
Insert the memory cartridge into the cartridge slot. Its slightly curved
5
shape ensures that the cartridge can only be fitted correctly. Push
firmly to seat the cartridge.
Firmly close the top cover and switch on the power.
6
Insert memory
cartridge
Switch down
