This example consists of two parts: a graphic and a line. The origin of the direct
graphic is defined the same as the origin of a normal graphic. In this example,
the coordinates for the origin of the complicated graphic are X0,Y450. However,
once you enter Direct Graphics mode, your printer loads the information in the
reverse Y direction. Each column of the graphic loads from the bottom to the
top. Your Y coordinates now start at 0 from the bottom left corner and increase
in size as the data loads. So, the printer starts loading data for the complicated
graphic at X0,Y450 and loads up to X0,Y425. Likewise, the data for the line
starts loading at X19,Y450 and loads up to X19,Y0.
