5. Connect temperature sensor (C) with
connect wire (D. Install the cover
according to Figure 2, then fix the upper
fire box according to Fig. 1. See Fig. 5.
6. Unscrew and remove panel on the left
side. See Fig. 6. (For Model # CRHFD32RT-M-
MO (Item # 0293807), FBD32 series only)
7. Remove blower access panel. See Fig. 7.
(For PC32VFC and PC36VFC series only)
6
Fig. 5
D
C
Fig. 6
Fig. 7
