VENTED NATURAL GAS LOGS
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-573-0674, 8:00 am - 4:30 pm CST,
Monday through Friday or email customerservice@usaprocom.com
MODELS
WAN18N-2
WAN24N-2
PFS
®
US
Advertisement
Table of Contents
Related Manuals for Procom WAN18N-2
Summary of Contents for Procom WAN18N-2
- Page 1 VENTED NATURAL GAS LOGS MODELS WAN18N-2 WAN24N-2 ® WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other flammable va- pors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Specifications ..........3 Operation ..........11 Safety ............3 Care and Maintenance ......12 Product Features ........5 Accessories ..........12 Local Codes..........5 Troubleshooting ........13 Unpacking..........5 Replacement Parts ........14 Air For Combustion and Ventilation ... 6 Parts ............ -
Page 3: Specifications
The fireplace must include a working flue and The charts indicate technical information venting system with the minimum openings regarding the installation of your gas log set. shown as below. Model WAN18N-2 WAN24N-2 Gas Type Natural Natural BTU Input* 45,000 BTU/Hr... - Page 4 SAFETY 7. To reduce the creation of soot, follow the WARNING: Any change to instructions in Care and Maintenance, this log set or its controls can page 15. be dangerous. 8. Do not allow fans to blow directly into the fireplace.
-
Page 5: Product Features
PRODUCT FEATURES ON/OFF SAFETY PILOT VALVE KIT WITH PROPANE/LP CONVERSION An optional on/off valve/safety pilot kit with a piezo ignitor is available for this appliance. This system requires no matches, batteries, or other sources to light. You must use this optional system for Propane/LP conversion. -
Page 6: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: Before installing WARNING: If the area in which the heater may be operated does in a solid fuel burning fireplace, the chimney flue and firebox not meet the required volume for indoor combustion air, combus- must be cleaned of soot, creo- sote, ashes, and loose paint by tion and ventilation air shall be... - Page 7 INSTALLATION INSTALLING DAMPER CLAMP Secure the damper stop clamp provided to Damper the leading edge of the damper as shown in Clamp Figure 2. If for any reason this clamp doesn't Damper work on your fireplace, another suitable clamp or permanent stop must be installed, or the damper blade must be cut or removed.
- Page 8 INSTALLATION Installation and Gas Connection 1. Place the burner pan assembly in the Connector center of the fireplace floor. Make sure Tube the front of pan faces forward. 2. Thread the gas supply fitting to the fire- place gas supply pipe. Use thread sealant. 3.
- Page 9 INSTALLATION CHECKING GAS CONNECTIONS WARNING: Never use an WARNING: Test all gas piping open flame to check for a leak. and connections for leaks after Apply a noncorrosive leak detec- installing or servicing. Correct tion fluid to all joints. Bubbles all leaks immediately.
- Page 10 INSTALLATION TESTING BURNER FOR LEAKS 4. When the burner is tested and leak free, WARNING: Never check for observe the individual tongues of flame gas leaks with open flame. on the burner. Note: Let the burner manifold cool first 1. Generously apply a noncorrosive leak before removing to unclog port blockages.
-
Page 11: Operation
INSTALLATION 3. Place remaining logs as shown in Figures 10 and 11. Log #4 Log #5 Log #3 Log #6-1 Log #6-3 Log #6-2 Figure 11 - Installing Logs #6-1, #6-2 & #6-3 Figure 10 - Installing Logs #3, #4 & #5 OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING not use any phone in your building. -
Page 12: Care And Maintenance
OPERATION GAS SHUTOFF VALVE OPERATION Flame Adjustment Shutting Off Appliance Adjust the flame ON/OFF by turning the gas Turn gas shutoff valve clockwise to the shutoff valve counterclockwise to open OFF position. or clockwise to close, as necessary. CURING LOGS During the 2-3 hour appliance curing period, To ensure proper curing of the logs: you may detect an odor from the appliance... -
Page 13: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. -
Page 14: Replacement Parts
TROUBLESHOOTING Problem Possible Cause Corrective Action Log set produces a click- 1. Metal expanding while heat- 1. This is common with most ing/ticking noise just after ing or contracting while cool- log sets. If noise is exces- burner is lit or shut off. ing. -
Page 15: Parts
PARTS MODELS WAN18N-2 AND WAN24N-2 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 14 of this manual. ITEM PART # DESCRIPTION 3/8" Female x 5/8" BL050-01 Flare Adapter... -
Page 16: Warranty
We make no other warranty, expressed or implied. LIMITED WARRANTY ProCom Heating, Inc. warrants this product to be free from defects in materials and components for ONE (1) year from the date of first purchase, provided that the product has been properly installed by a qualified installer in accordance with all local codes and instructions furnished with the unit, operated and main- tained in accordance with all applicable instructions.
