Summary of Contents for Hay AAT 15
- Page 1 – INSTRUCTION MANUAL – ABOUT A TABLE AAT 15 | AAT 20 DESIGN BY HEE WELLING & HAY...
- Page 3 – PARTS – Tabletop x1 Column x2 Leg x4 Support x4 Bracket x2 Screw x12 Adjustable Expanding nut x8 glider x4 Screw x8 Screw x2 Allen key x1...
- Page 4 Protect the table top from scratches and other damage while assembling.
- Page 5 Slide the part into the part and press it down gently. Repeat this step on all parts. Place the part into the part. Repeat this step on all parts. ...
- Page 6 Place the part in the shown holes of the parts. Screw 4 x parts in the shown holes of the part, using the Allen key ( ...
- Page 7 Screw 1 x part in the shown hole of the part, using the Allen key ( Place the part into the part and press it down gently. Repeat this step on the parts.
- Page 8 Place the part in the shown holes of the part. Repeat this step on all parts. Place the part in the shown holes of the parts. ...
- Page 9 Screw 4 x parts into the shown holes of the part using the Allen key ( Screw 1 x part in the shown hole of the part using the Allen key ( ...
- Page 10 Screw the part into the hole of the part. Repeat this step on all parts. ...
- Page 11 Screw the part to the tabletop using the parts. NOTICE Make sure the table is upright when mounting the base.
- Page 12 If the table is standing on an uneven floor, adjust the gliders until stable.
-
Page 13: Care And Maintenance
Please find our Care & Maintenance guide by scanning the QR code You can find more relevant information on AAT 15 & AAT 20 by scanning the QR codes You can also find the same information here hay.dk/downloads... - Page 16 Havnen 1 8700 Horsens Denmark +45 4282 0282 / hay@hay.com www.hay.com 22/12/2021...
