H-9729
PINNACLE MESH CHAIR
TOOL NEEDED
Allen Wrench
(Included)
Seat Cushion x 1
Backrest x 1
Caster x 5
1.
Insert casters into
legs on underside of
five-star base. Turn
base upright. Insert
gas lift into center of
base. (See Figure 1)
2. Align armrest with holes on bottom of seat cushion.
Use three 1/4 x 1
⁄
" screws (I) to attach. Repeat on
3
4
opposite side. (See Figure 2)
NOTE: Use Allen
wrench to tighten
all screws.
PAGE 1 OF 6
1-800-295-5510
uline.com
Gas Lift x 1
Armrest x 2
ASSEMBLY
Figure 1
Gas Lift
Figure 2
I
Front
PARTS
I
Screw x 8
5-Star Base x 1
1/4 x 1¾"
L
Mechanism x 1
Screw x 1
M8 x 35 mm
3. Align mechanism with holes on bottom of seat
cushion. Use two 1/4 x 1¾" screws (I) in the front,
two 1/4 x 1¼" screws (J) in the back and four small
washers (M) to attach. (See Figure 3)
Figure 3
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Hardware Kit
J
K
Screw x 2
1/4 x 1¼"
M8 x 20 mm
M
N
Small
Washer x 4
Washer x 3
J
J
I
I
M
Front
0322 IH-9729
