CONTENTS
Package Contents .............................2
Product Registration..........................2
Features & Benefits .............................3
Setup .................................................5
Set the Time, Date & Units ................6
Placement Guidelines .......................6
Operation .........................................7
Alarm Setup ......................................8
Visit us online at www.acurite.com/support
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions?
We're here to help!
AcuRite Iris
Care & Maintenance ........................8
Calibration ........................................8
Troubleshooting ................................9
Specifications ..................................10
Customer Support ........................... 1 1
Warranty......................................... 1 1
FCC Information ............................. 1 1
Instruction Manual
Mini Display
®
model 06106
Advertisement
Table of Contents
Related Manuals for ACU-RITE Iris 06106
Summary of Contents for ACU-RITE Iris 06106
-
Page 1: Table Of Contents
Instruction Manual AcuRite Iris Mini Display ® model 06106 CONTENTS Care & Maintenance ......8 Package Contents ......2 Calibration ........8 Product Registration......2 Troubleshooting ........9 Features & Benefits ......3 Specifications ........10 Setup ..........5 Customer Support ......1 1 Set the Time, Date & Units ....6 Warranty......... -
Page 2: Package Contents
Congratulations on your new AcuRite product! To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product. Locate the tab and peel off to remove. -
Page 3: Features & Benefits
Features & Benefits Front of Display 1. Current Outdoor Temperature 12. Current Indoor Temperature 2. Records Button 13. Current Barometric Pressure Press to cycle through available daily and Arrow indicates the direction the pressure all-time records. is trending. 3. Current Outdoor Humidity 14. - Page 4 Back of Display A-B-C 1. Integrated Hanger Button For easy wall mounting. For setup preferences. 2. A-B-C Switch Button ID code that must match sensor’s A-B-C For setup preferences. switch to ensure units synchronize. 9. SET Button 3. Display Stand For setup preferences.
-
Page 5: Setup
SETUP Display Setup Set the A-B-C Switch Locate the A-B-C switch inside the battery compartment. Set the A-B-C switch to A, B or C. You must select the same letter choices for both the display and the sensor in order for the units to synchronize. -
Page 6: Set The Time, Date & Units
Set the Time, Date & Units Press and release the “SET” button, located on the back of the display, to enter SET MODE. Once in set mode, the preference you are currently setting will blink on the display. To adjust the currently selected (flashing) item, press and release the “ ” or “ ” buttons (press and HOLD to fast adjust). -
Page 7: Operation
OPERATION Using the AcuRite Iris Mini Display ® Learning Mode Self-calibrating forecasting uses a unique algorithm to analyze changes in pressure over a time period (called Learning Mode) to determine your altitude. After 14 days, the Learning Mode icon disappears from the display screen. At this point, the self-calibrated pressure is tuned in to your location and the unit is ready for superior weather prediction. -
Page 8: Care & Maintenance
Programmable Alarms This display features programmable alarms that sound an alert to notify you when a value (for outdoor temperature, humidity, wind speed or rainfall) has been reached or exceeded. When an alarm is triggered, the display emits an audible beep and flashes data in the affected category. You can customize the alarms by turning ON or OFF the alarms you’d like activated or deactivated, and by inputting your own values to trigger the alarm. -
Page 9: Troubleshooting
Troubleshooting Problem Possible Solution If the wireless signal indicator shows no bars: • Relocate the display and/or the outdoor sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet (.9 m) away from No outdoor sensor electronics that may interfere with the wireless communication reception... -
Page 10: Specifications
Troubleshooting Cont’d Problem Possible Solution • What is wind reading being compared to? Pro weather stations are typically mounted at 30 ft high or more. Make sure to compare data using a sensor positioned at the same mounting height. Inaccurate wind readings •... -
Page 11: Customer Support
Customer Support AcuRite customer support is committed to providing you with best-in-class service. For assistance, please have the model number of this product available and visit acurite.com/support. ► ► Installation Videos Register your Product ► ► Instruction Manuals Replacement Parts ►... - Page 12 www.AcuRite.com © Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copyrights are the property of their respective owners. AcuRite uses patented Printed in China technology.
