- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS 2-jaw parallel gripper, pneumatic GPP5000 series 3-jaw concentric gripper, pneumatic GPD5000 series DDOC00196 THE KNOW-HOW FACTORY www.zimmer-group.com...
-
Page 3: Table Of Contents
10.4.2 Installing the gripper fingers ....................................15 10.5 Installing the support structure ......................................16 11 Maintenance ....................................17 12 Decommissioning/disposal ..............................18 13 Declaration of Incorporation ..............................19 Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 4: Supporting Documents
General notices contain usage tips and valuable information, but no warnings of dangers to health. INFORMATION This category contains useful tips for handling the product efficiently. Failure to observe these tips will not result in damage to the product. This information does not include any information relevant to health or workplace safety. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 5: Safety Notices
► Do not reach into the operational range of the product. ► Observe the specified maintenance intervals and specifications regarding the quality of the operating material. ► When using the product under extreme conditions, adjust the maintenance interval according to the degree of contamination. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 6: Proper Use
5 Product description 5.1 Type plate A type plate is attached to the housing of the product. The article number and the confirmation number are shown on the type XX-XXXXXX plate. Article number Confirmation number Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 7: Functional Description
8 Accessories/scope of delivery INFORMATION If any accessories not sold or authorized by Zimmer GmbH are used, the function of the product cannot be guaranteed. Zimmer GmbH accessories are specifically tailored to the individual products. ► For optional accessories and those included in the scope of delivery, refer to our website. -
Page 8: Transportation/Storage/Preservation
► Clean all components. There must be no soiling left on the components. ► Visually inspect all components. ► Remove all foreign substances. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 9: Installation
► Observe the tightening torque of the mounting screws. ► Verify the permitted load capacity of the required screw connections in accordance with VDI 2230. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 10: Installing Gpp5000
► Position the product on the mounting piece using centering sleeves. ► Mount the product on the mounting piece using the appropriate mounting screws. Mounting screw Centering Disc Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 11: Installing Gpd5000
► Mount the product on the mounting piece using the appropriate mounting screws. Mounting screw Straight pins Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 12: Installing The Energy Supply
► Use compressed air in accordance with DIN ISO 8573-1 [4:4:4]. ► Insert the screw fittings into the provided connections. Connector INFORMATION Multiple alternative connections are available. No screw fittings have to be installed in the alternative connections. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 13: Installing Accessories
Gripper jaw Adjusting screw Clamping screw Mounting block Inductive sensor Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... - Page 14 INSTALLATION AND OPERATING INSTRUCTIONS:GPP5000/GPD5000 INFORMATION ► For further information on installing the magnetic field sensors, refer to the current installation and operating instructions for the product on our website. Magnetic field sensor Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com...
-
Page 15: Installing The Gripper Fingers
GPD5000 series: • Strength class of the mounting screws is at least 12.9 (DIN EN ISO 4762) Mounting screw Gripper finger Centering Disc Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 16: Installing The Support Structure
It is possible to remove the cover plate in order to use a customer-specific support structure. For installing a support structure, there are additional fits under the cover plate. Dimension B Dimension A Cover plate Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 17: Maintenance
Ö Dismantling and reassembling the product without authorization may result in complications, as special installation equipment is required in some cases. Zimmer GmbH accepts no liability for any resulting malfunctions or damage. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 18: Decommissioning/Disposal
► Dispose of the components properly according to the material groups. ► Comply with the locally applicable environmental and disposal regulations. Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com... -
Page 19: Declaration Of Incorporation
Authorized representative for the (Place and date of issuance) Martin Zimmer compilation of relevant technical (Legally binding signature) documents Managing Partner Zimmer GmbH • Im Salmenkopf 5 • 77866 Rheinau, Germany • +49 7844 9138 0 • www.zimmer-group.com...
