Image Engineering GEOCAL User Manual page 19
Hide thumbs
Also See for GEOCAL:
- User manual (15 pages) ,
- User manual (16 pages) ,
- User manual (48 pages)
Table of Contents
Advertisement
API (C++)
General description hardware
Power supply/consumption
Ports
Weight
Operating conditions
Requirements on the device under test (DUT)
Max. dimensions
Usable FoV
Image Engineering
Available as a separate option
25W 5V/5A / Pmax = 2W
USB type B
GEOCAL: approx. 4.5 kg
GEOCAL XL: approx. 10 kg
15 - 35°C
GEOCAL: max. diameter of the camera lens: 77 mm
GEOCAL XL: max. diameter of the camera lens: 155mm
Approx. 30 – 180° (deviating values will have to be tested)
Seite 19 von 19
