RTKA489000DE0000BU
The
RAA489000
is a digitally configurable buck-boost
battery charger with USB-C® Port Controller (TCPC).
The battery charging function supports Narrow
Voltage Direct Charging (NVDC) and USB Power
Delivery (PD) programmable power supply output
supplies. The TCPC controller integrates TCPC PHY,
CC-Logic, and VCONN switches. All RAA489000
blocks connected to the adapter/USB pin (CC1, CC2,
VBUS) are protected from input overvoltage events
up to 28V. The back-to-back NFET driver and VBUS
self-discharge control further simplify the USB PD
designs.
The RAA489000 supports reverse buck, boost, or
buck-boost operation to the adapter port (OTG mode)
from 2- to 4-cell batteries that allow configurations to
support USB PD output for Programmable Power
Supply (PPS) ports. Because of the on-chip TCPC
and Renesas advanced R3™ Technology,
RAA489000 is fully compliant with USB PD Sink Fast
Role Swap (FRS) specification by monitoring CC line
and bringing VBUS voltage back to a safe range
rapidly. The RAA489000 has dual SMBus/I
supporting simultaneous direct charger function
programming and CC line traffic through TCPCI,
when operating with a USB-C Port Manager (TCPM)
such as the Renesas R9A02G015, to form a
complete USB PD compliant solution for single-port or
multi-port applications.
The RAA489000 battery charger supports all NFETs
solution and supports system power from the adapter,
battery, or a combination of both. The on-chip ADC
monitors the charging input voltage/current, battery
voltage, charging/discharging current, and the battery
temperature. For Intel™ IMVP compliant systems, the
RAA489000 includes PROCHOT#.
The RTKA489000DE0000BU evaluation board is
designed to demonstrate the performance of the
RAA489000. From the PROG pin to GND, the resistor
can be used to program the default value numbers of
the battery in series, the switching frequency, and the
adapter current limit charging function. The default
value numbers can also be set by SMBus.
R16UH0006EU0100 Rev.1.0
Apr 16, 2021
Features
▪ Buck-Boost NVDC charger for 2-, 3-, or 4-cell Li-ion
batteries using all NFET transistors
▪ USB-C Port Controller (TCPC) with integrated
TCPC PHY, CC-Logic
▪ Dual SMBus/I2C ports for charger programming
and CC line traffic
▪ Internal 500mΩ VCONN MUX for up to 1.6A
▪ Input voltage range: 3.9V to 23.4V (no dead zone)
▪ System/battery output voltage: 3.9V to 18.304V
▪ 28V protection for CC1/CC2/VBUS
▪ Adapter Crash Prevention with adapter current and
battery current regulation
▪ PROCHOT# and PSYS outputs, IMVP compliant
▪ Support Intel VMIN Active Protection (VAP)
▪ Internal 8-bit ADC for charger operation telemetry
▪ Software configurable for DFP, UFP, or DRP
▪ USB-C PD Sink Fast Role Swap (FRS) and PPS
support
2
C ports
▪ Pass-Through-Mode (PTM) in forward direction
▪ Battery Ship mode - IC ultra-low power state
▪ Supports JEITA compliance autonomous charge
▪ Dynamic Voltage Compensation (DVC) support for
multi-port charging applications
▪ USB Power Delivery (PD) 3.0 and Programmable
Power Supply (PPS) certified
▪ 5x5 40 Ld QFN package
▪ UL 2367, IEC 62368-1: File No. E520109
Specifications
▪ VIN = 3.9V to 23.4V (no dead zone)
▪ VOUT = 3.9V to 18.304V
▪ MAX charge current up to 6A
Evaluation Board Manual
© 2021 Renesas Electronics
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTKA489000DE0000BU and is the answer not in the manual?

Questions and answers

Summary of Contents for Renesas RTKA489000DE0000BU

  • Page 1 ▪ Battery Ship mode - IC ultra-low power state when operating with a USB-C Port Manager (TCPM) ▪ Supports JEITA compliance autonomous charge such as the Renesas R9A02G015, to form a ▪ Dynamic Voltage Compensation (DVC) support for complete USB PD compliant solution for single-port or multi-port charging applications multi-port applications.
  • Page 2 RTKA489000DE0000BU Evaluation Board Manual ASRC VSYS VBUS VSYS CSOP CSIN CSIP CSON ASGATE BGATE ASRC ACLIM VBAT RAA489000 RLIM 1S-4S Battery VBUS AMON/BMON Bottom Pad PROCHOT# OTGEN/CMIN ALERT_B BATGONE/NTC ALERT_C RTHM Figure 1. RTKA489000DE0000BU Application Diagram R16UH0006EU0100 Rev.1.0 Page 2 Apr 16, 2021...
  • Page 3: Table Of Contents

    Configuring the RTKA489000DE0000BU for OTG Mode ....... . . 11...
  • Page 4: Installing The Raa489000 Software

    RTKA489000DE0000BU Evaluation Board Manual Installing the RAA489000 Software The RAA489000 Control Software communicates with the RAA489000 controller using the USB to on-board SMBus Graphical User Interface (GUI). The GUI facilitates access to the RAA489000 SMBus registers. This section describes how to install, start, and use the GUI.
  • Page 5: Installing The Usb Driver

    RTKA489000DE0000BU Evaluation Board Manual Figure 3. RAA489000 Control Software Installer 4. Follow the instructions to accept the two End User License Agreements to complete the software installation. 5. Click Close Menu from the installation wizard. Installing the USB Driver This process explains how to install the SMBus to USB interface driver.
  • Page 6 RTKA489000DE0000BU Evaluation Board Manual Figure 5. RAA489000 Successful Driver Installation 4. If the installation fails the Digital Signature required in Windows 10 or security settings, complete the following steps to bypass it. Note: To complete the process, print and complete the following steps. The system restarts and these instructions are needed.
  • Page 7: Using The Gui

    Connect the RTKA489000DE0000BU to a power supply before using the SMBus GUI. Setting the USB Connection Connect the USB cable from the USB port of the computer to connector J20 of the RTKA489000DE0000BU. Starting the GUI To start the GUI, navigate to the Start menu, then select All Programs → Renesas → RAA489000 SMBus Control Tool.
  • Page 8: Troubleshooting The Gui

    1. Ensure the driver files for the USB interface are installed correctly. The driver files are in the USB-I2C Driver folder. 2. Check the USB cable connections from the RTKA489000DE0000BU to the USB port of the computer. 3. Try different sequences: plug in the RTKA489000DE0000BU first or start the GUI first.
  • Page 9: Regulating System Voltage

    RTKA489000DE0000BU Evaluation Board Manual PHASE 1 PHASE2 VSYS Negative VBUS Negative VSYS Positive VBUS Positive VBAT Negative VBAT Negative JP10A JP6A JP11 JP3A USB-I2C Connector SYNC INPUT OTGEN BATGONE Figure 7. RTKA489000DE0000BU Connections Regulating System Voltage 1. Set the power supply to 5V. With the output disabled, connect the (+) end to J1A and the (-) end to J2A.
  • Page 10: Configuring The Rtka489000De0000Bu For Charging Mode

    Note: A green check mark in the USB Interface status indicates the GUI is ready to communicate with the RTKA489000DE0000BU. If the USB Interface shows a red X, the GUI is not ready to communicate with the RTKA489000DE0000BU. Click the Reset USB button until a green check mark appears in the USB Interface. If the green check mark does not appear, check the USB connection.
  • Page 11: Configuring The Rtka489000De0000Bu For Trickle Charging Mode

    Note: Ensure the input current does not reach the input current limit value, especially for a small VIN input. Configuring the RTKA489000DE0000BU for Trickle Charging Mode 1. Complete steps 1 through 5 in Configuring the RTKA489000DE0000BU for Charging Mode without any changes.
  • Page 12 RTKA489000DE0000BU Evaluation Board Manual Figure 9. OTGVoltage and OTGCurrent Settings in GUI 5. Select the Control0 & 1 Registers tab. 6. In the Control1 Register column, select 1: Enable in OTG Function to enable OTG, then click Write. See Figure R16UH0006EU0100 Rev.1.0...
  • Page 13: Configuring The Rtka489000De0000Bu As Source

    8. Increase the electrical load slowly and monitor the load voltage. If the load current is less than the OTGCurrent limit value, the load voltage is regulated at the setting value. Configuring the RTKA489000DE0000BU as Source 1. Set the battery emulator voltage at a constant value between 5.8V and 15V. Connect battery leads J5A and J6A with the output disabled.
  • Page 14 RTKA489000DE0000BU Evaluation Board Manual Figure 11. Configuring RAA489000 Through TCPC 5. In the Write To Register box, set Register Address to 0x0080 and Data In to 0x0010, then click Write to enable TCPC to control power. See Figure R16UH0006EU0100 Rev.1.0...
  • Page 15: Configuring The Rtka489000De0000Bu As Sink

    9. Increase the electrical load slowly and monitor the load voltage. If the load current is less than the current limit value, set in Step 7, the load voltage would be regulated at the voltage value, set in Step 6. Configuring the RTKA489000DE0000BU as Sink 1. Complete Steps 1 and 2 in Regulating System Voltage.
  • Page 16: Board Design

    RTKA489000DE0000BU Evaluation Board Manual In the Write To Register box, set Register Address to 0x0023 and Data In to 0x0055, then click Write to configure the RTKA489000DE0000BU as Sink. Measure VSYS using the DMM across (+) and (-). VSYS should read 8.38V.
  • Page 17: Guidelines For Pcb Layout Guidelines

    PHASE1 Run these two traces in parallel fashion with decent width. Avoid any sensitive analog signal trace from crossing over or getting close. Renesas recommends routing the PHASE1 trace to the high- UGATE1 side MOSFET source pin instead of general copper.
  • Page 18 RTKA489000DE0000BU Evaluation Board Manual Pin # Pin Name Layout Guidelines BOOT1 Switching pin. Place the bootstrap capacitor in the general proximity of the controller. Use sufficiently wide traces. Avoid any sensitive analog signal trace from crossing over or getting close.
  • Page 19 UGATE2 Run these two traces in parallel fashion with sufficient width. Avoid any sensitive analog signal trace from crossing over or getting close. Renesas recommends routing the PHASE2 trace to the PHASE2 high-side MOSFET source pin instead of general copper.
  • Page 20: Schematics Drawings

    Schematics Drawings Address: Four selections for both TCPC and Charger I2C (1=master default, 2,3,4=slave default) Addresses for the CC and CHG are paired. 1 – CC 0x20h CHG 0x12h 2 – CC 0x22h CHG 0x92h 3 – CC 0x24h CHG 0x94h When ASGATE FETs are not populated, do not leave ASRC floating 4 –...
  • Page 21 CONNECTOR Figure 16. Schematic (2/2)
  • Page 22: Bill Of Materials

    RTKA489000DE0000BU Evaluation Board Manual Bill of Materials Reference Manufacturer Designator Description Manufacturer Part Number PWB-PCB, IMAGINEERING INC RTKA489000DE0000BU RTKA489000DE0000BU, ROHS CAP-POSCAP, SMD, Panasonic 25TQC15MYFB 3.5x2.8mm, 15µF, 25V, 20%, 100mΩ, ROHS C105a, C106a CAP CER 4.7µF 10V X5R Murata GRM155R61A475MEAAD 0402 C109a CAP, SMD, 0402, 2.2µF,...
  • Page 23 RTKA489000DE0000BU Evaluation Board Manual J1a, J3a, J5a CONN-GEN, BIND.POST, Johnson Components 111-0702-001 INSUL-RED, THMBNUT- J2a, J4a, J6a CONN-GEN, BIND.POST, Johnson Components 111-0703-001 INSUL-BLK, THMBNUT- TP68a, TP69a CONN-SCOPE PROBE Tektronix 131-4353-00 TEST PT, COMPACT, PCB MNT, ROHS TP66a, TP67a, CONN-SCOPE PROBE...
  • Page 24 RTKA489000DE0000BU Evaluation Board Manual 225W SURFACE MOUNT DFLT30A TRANSIENT VOLTAGE SUPPRESSOR D7, D9 TVS DIODE 24V Comchip Technology CPDQC24VEU-HF 2DFN/0402C/SOD923F D8, D10 ESD Suppressors / TVS Littelfuse SP1124-01UTG Diodes 30kV 24V 20A TVS Diod uDFN-2 LED1a, LED2a, LED3a LED, SMD, 1206, GREEN,...
  • Page 25 RTKA489000DE0000BU Evaluation Board Manual R15a, R16a, R123a, RES, SMD, 0603, 2.21k, Vishay/Dale CRCW06032K21FKEAC R124a 1/10W, 1%, TF, ROHS R97a RES, SMD, 0603, 3.48k, Panasonic ERJ-3EKF3481V 1/10W, 1%, TF, ROHS R24a RES, SMD, 0603, 4.53k, Panasonic ERJ-3EKF4531V 1/10W, 1%, TF, ROHS R27a RES, SMD, 0603, 6.98k,...
  • Page 26 RTKA489000DE0000BU Evaluation Board Manual L3, L4 Do Not Populate Or Purchase Q6_3x3, Q7_3x3 Do Not Populate Or Purchase C107b, C108b, C109b, Do Not Populate Or C198a Purchase C7a-C11a, C19a, C24a, Do Not Populate Or C88a-C92a Purchase C27a, C18a, C29a, C34a...
  • Page 27: Board Layout

    RTKA489000DE0000BU Evaluation Board Manual Board Layout Figure 17. Top Silkscreen R16UH0006EU0100 Rev.1.0 Page 27 Apr 16, 2021...
  • Page 28 RTKA489000DE0000BU Evaluation Board Manual Figure 18. Top Layer R16UH0006EU0100 Rev.1.0 Page 28 Apr 16, 2021...
  • Page 29 RTKA489000DE0000BU Evaluation Board Manual Figure 19. Layer 2 R16UH0006EU0100 Rev.1.0 Page 29 Apr 16, 2021...
  • Page 30 RTKA489000DE0000BU Evaluation Board Manual Figure 20. Layer 3 R16UH0006EU0100 Rev.1.0 Page 30 Apr 16, 2021...
  • Page 31 RTKA489000DE0000BU Evaluation Board Manual Figure 21. Layer 4 R16UH0006EU0100 Rev.1.0 Page 31 Apr 16, 2021...
  • Page 32 RTKA489000DE0000BU Evaluation Board Manual Figure 22. Layer 5 R16UH0006EU0100 Rev.1.0 Page 32 Apr 16, 2021...
  • Page 33 RTKA489000DE0000BU Evaluation Board Manual Figure 23. Layer 6 R16UH0006EU0100 Rev.1.0 Page 33 Apr 16, 2021...
  • Page 34 RTKA489000DE0000BU Evaluation Board Manual Figure 24. Layer 7 R16UH0006EU0100 Rev.1.0 Page 34 Apr 16, 2021...
  • Page 35 RTKA489000DE0000BU Evaluation Board Manual Figure 25. Bottom Layer R16UH0006EU0100 Rev.1.0 Page 35 Apr 16, 2021...
  • Page 36 RTKA489000DE0000BU Evaluation Board Manual Figure 26. Bottom Silkscreen R16UH0006EU0100 Rev.1.0 Page 36 Apr 16, 2021...
  • Page 37: Typical Performance

    RTKA489000DE0000BU Evaluation Board Manual Typical Performance VADP 1V/Div VBAT 2V/Div PHASE1 1V/Div BGATE 2V/Div VSYS 2V/Div VSYS 1V/Div VDD 1V/Div VDD 1V/Div ms/Div ms/Div Figure 27. Start Up with Battery Figure 28. Start Up with 5V Adapter VADP 1V/Div VADP 1V/Div...
  • Page 38 RTKA489000DE0000BU Evaluation Board Manual VSYS 2V/Div VSYS 2V/Div ISYS 2A/Div ISYS 2A/Div IADP 1A/Div IADP 1A/Div IBAT 2A/Div IBAT 2A/Div 1 s/Div 1 s/Div Figure 33. Boost Mode, Output Voltage Loop to Adapter Figure 34. Boost Mode, Charge Current Loop to Adapter...
  • Page 39 RTKA489000DE0000BU Evaluation Board Manual VSYS 2V/Div VSYS 2V/Div ISYS 2A/Div ISYS 2A/Div IADP 1A/Div IADP 1A/Div IBAT 2A/Div IBAT 2A/Div 1 s/Div 1 s/Div Figure 37. Buck Mode, Output Voltage Loop to Adapter Figure 38. Buck Mode, Charge Current Loop to Adapter...
  • Page 40: Ordering Information

    RTKA489000DE0000BU Evaluation Board Manual Ordering Information Part Number Description RTKA489000DE0000BU RAA489000 buck-boost charger evaluation board Revision History Revision Date Description Apr 16, 2021 Initial release R16UH0006EU0100 Rev.1.0 Page 40 Apr 16, 2021...
