- Page 1 Installation Guide Rev.01 07/22...
-
Page 2: Table Of Contents
SIGS39 Contents PAGE 3 1.0 - ALARM POSITIONING 2.0 - ACCESSORIES POSITIONING PAGE 4 2.1 - Override key receptacle PAGE 4 2.2 - Contact switch (Thatcham Requirement) PAGE 4 2.3 - Infra-Red Sensor PAGE 4 PAGE 5 3.0 - ALARM UNIT SEALING 4.0 –... -
Page 3: Alarm Positioning
1.0 – Alarm Positioning For maximum security the alarm should be mounted inside the caravan. To ensure maximum sound volume in the event of an alarm trigger it is recommended that the alarm is mounted close to an external air vent, if this is not possible it may be necessary to install an air vent. -
Page 4: Accessories Positioning
2.3 – Infra-Red Sensor Additional interior security may be obtained by installing a PIR sensor, Scorpion offer a wireless PIR sensor (SIG909) should be mounted onto the ceiling of the caravan and has a detection range of approximately 8M (diameter) when mounted at a ceiling height between 2 - 2.5M. -
Page 5: Alarm Unit Sealing
3.0 - Alarm Unit Sealing The alarm unit will be supplied with the rubber seal and plastic rectangular flange already fixed in place, the following is for informational purposes should the unit need to be disassembled and reassembled. To seal the alarm, position the rubber cap over the external edge of the alarm housing. -
Page 6: Alarm Positiong For Maximum Sensitivity
4.0 - Alarm Positioning for Maximum Sensitivity To ensure the correct operation of the built-in motion sensor install the alarm flat as illustrated below, this will allow coverage on all directions. The siren may be mounted with the siren cone facing upward or downward. - Page 7 To front of To rear of Caravan Caravan Figure 4: motion sensor operation with siren facing sideways. The alarm will only detect in the direction as indicated by the arrow in the drawing above. In order for alarm to correctly detect a change of inclination the siren cone should either point towards the front of the vehicle or towards the rear of the vehicle.
-
Page 8: Electrical Connections
5.0 - ELECTRICAL CONNECTIONS WIRE COLOUR CONNECTION Black marked “M” Connect to negative Black marked “R” Connect to positive Orange Not Used Orange Not Used Black marked “G” +15 Ignition Green/Brown Connect to contact switch or insulate Pink Positive output on alarm trigger White/Violet Device pairing Black with Red sleeve... -
Page 9: Wiring Diagram And Pinout
6.0 - WIRING DIAGRAM AND PINOUT Rev.01 07/22... -
Page 10: Pairing New Devices
7.0 - PAIRING NEW DEVICES 7.1 - With GREEN/BROWN wire ground connection The alarm is supplied with 2 remote controls and 1 override key but other optional devices can be added. To pair a new device, proceed as follows: • Arm and then disarm the alarm via remote control or override key. -
Page 11: Without Green/Brown Wire Ground Connection
7.2 - Without GREEN/BROWN wire ground connection To pair a new device, proceed as follows: • Arm and then disarm the alarm via remote control or override key. • Press the ignition simulation switch to ON. • The status LED will turn ON for 1 sec. •... -
Page 12: Programmable Features
8.0 - PROGRAMMABLE FEATURES To either enable or disable one of the programmable features proceed as indicated hereafter. NB: Remember to ALWAYS arm and disarm the alarm before programming. Rev.01 07/22... -
Page 13: Programming Example
After pressing both buttons simultaneously (step 4), program the features according to your needs. 9.0 - PROGRAMMING EXAMPLE To help you understand the programming procedure, here below is an example showing how to enable both features. Keep in mind that, at every button press, the system automatically scrolls to the next feature. •... -
Page 14: Remote Control
10.0 - REMOTE CONTROL The remote control has 2 different function buttons each of which corresponds to a control signal that activates a selected action according to the operational condition and alarm configuration. The textured button is for arming/disarming the alarm while the smooth button is used to exclude or trigger the siren. -
Page 15: Waste Electrical And Electronic Equipment
11.0 - WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT The present device falls within the field of application of the current WEEE Directive. The crossed- out wheeled bin symbol on the equipment or on its packaging indicates that the product, at the end of its useful life, must be discarded separately from other waste to allow adequate treatment and recycling.
