IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A.
Seat
1 pc.
D.
Back
1 pc.
Hardware List
home
5675-10
Chair
M6x30
Hex Wrench
Head Cap Bolt (short)
1 pc.
2 pcs. (+1 extra)
Small
M6x45
Hex Wrench
Head Cap Bolt
6 pcs. (+1 extra)
1 pc.
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
B.
Side
1 pc.
E.
Seat Cushion
1 pc.
Spring Washer
8 pcs. (+1 extra)
M8x50
Head Cap Bolt (large)
4 pcs. (+1 extra)
C.
Side
1 pc.
F.
Back Cushion
1 pc.
Flat Washer
8 pcs. (+1 extra)
Wood Plug
4 pcs. (+1 extra)
888-680-7460
Advertisement
Table of Contents
Related Manuals for Homestyles 5675-10
Summary of Contents for Homestyles 5675-10
- Page 1 5675-10 Chair IMPORTANT Carefully remove all the parts from the carton and place them individually on a soft cloth to prevent scratches or other damage. Carefully and strictly follow these assembly instructions to ensure a completed product as designed. Do not use power tools above 8 volts to assemble.
- Page 2 Assembly Instructions 2/3 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ Keep Hex Wrench as the bolts may need to be tightened in the future.
- Page 3 Assembly Instructions /3 Velcro STEP 3 Use velcro on Seat Cushion (E) to attach to unit. Figure 3 Wood Plug STEP 4 Turn unit to its upright position. Slide Back Cushion (F) into position. Cover holes with Wood Plugs. (See Figure 3)
- Page 4 CARE INSTRUCTIONS Advisory Notes · Do not use power tools above 8 volts to assemble. · Periodic structural checks of this furniture should be undertaken. Do not use if there are any doubts about its fitness for purpose. · Exercise care so as to not trap fingers in any of the hinged parts of this furniture. ·...
