Arm Chair
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Seat
1 pc.
Hardware List
Hex Wrench
1 Pc.
Small
Hex Wrench
1 Pc.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Back
1 pc.
M6x20
Head Cap Bolt (short)
6 Pcs.(+1 extra)
C.
Leg
1 pc.
M6x25
Head Cap Bolt
2 Pcs.(+1 extra)
D.
Leg
1 pc.
