5. Operation Controls and Functions

5.1 Transmitter

Front Panel
1
No. Name
1 POWER LED
2 IN LED
3 LOOP LED
4
OUT(1~4) LED
Metal Enclosure
Black
Transmitter: 220mm (W) × 130mm (D) × 40mm (H)
Receiver: 140mm (W) × 65mm (D) × 18mm (H)
Transmitter: 853g
Receiver: 246g
Input: AC100 - 240V 50/60Hz, Output: DC 24V/2.7A
(US/EU standards, CE/FCC/UL certified)
35W
0°C ~ 40°C / 32°F ~ 104°F
-20°C ~ 60°C / -4°F ~ 140°F
20~90% RH (non-condensing)
IN LOOP 1 2
2 3 4
When the device is powered on, the red power LED will
be on.
When the HDMI IN port connects an active source device,
the green LED will be on.
When the HDMI LOOP OUT port connects an active
display device, the green LED will be on.
When the
3 4
Receiver, the corresponding green OUT LED will be on.
18Gbps HDMI 1x4 HDBaseT Splitter
3 4 OUT
Function Description
HDBT
OUTPUT port connects an HDBaseT
