6. EDID Mode

The defined EDID setting list of the product is shown as below:
EDID Mode
11111 1080P, Stereo Audio 2.0
11110 1080P, Dolby/DTS 5.1
11101 1080P, HD Audio 7.1
11100 1080I, Stereo Audio 2.0
11011 1080I, Dolby/DTS 5.1
11010 1080I, HD Audio 7.1
11001 1080P 3D, Stereo Audio 2.0
11000 1080P 3D, Dolby/DTS 5.1
10111 1080P 3D, HD Audio 7.1
10110
4K2K30Hz_444, Stereo Audio 2.0
4K2K30Hz_444, Dolby/DTS 5.1
10101
4K2K30Hz_444, HD Audio 7.1
10100
10011 4K2K60Hz_420, Stereo Audio 2.0
4K2K60Hz_420, Dolby/DTS 5.1
10010
10001 4K2K60Hz_420, HD Audio 7.1
10000 4K2K60Hz_444, Stereo Audio 2.0
01111 4K2K60Hz_444, Dolby/DTS 5.1
4K2K60Hz_444, HD Audio 7.1
01110
01101 4K2K60Hz_444, Stereo Audio 2.0 HDR
01100 4K2K60Hz_444, Dolby/DTS 5.1 HDR
01011 4K2K60Hz_444, HD Audio 7.1HDR
COPY_FROM_LOOP OUT
01010
COPY_FROM_HDBT OUT1
01001
COPY_FROM_HDBT OUT2
01000
COPY_FROM_HDBT OUT3
00111
00110 COPY_FROM_HDBT OUT4
00101 1080P, Stereo Audio 2.0
00100 1080P, Stereo Audio 2.0
1080P, Stereo Audio 2.0
00011
1080P, Stereo Audio 2.0
00010
1080P, Stereo Audio 2.0
00001
PC control mode
00000
