Command Code
RS-232 BYPASS Setting
Set RS-232 port connect to
s rs232 bypass HDBT out1 Receiver RS-232
port, y=0~5( 0=all,
hdbt y!
1~4= hdbt out 1~4 5=NC)
Get RS-232 port connect to
r rs232 bypass! HDBT out receiver RS-232
port
Set receiver control device
COM port setting, w=2400,
s device baud
w size x stop y 4800,9600,19200,38400,
57600,115200, x=7,8
parity z!
y=1,2, z=none, even,odd
set send RS232 command
wait time
s rs232 time x!
x=200~5000ms
Function Description Example
RS-232 connect to
s rs232 bypass HDBT OUT1
hdbt 1!
RS-232 not connect
to HDBT OUT
RS-232 connect to
HDBT OUT1
RS-232 connect to all
r rs232 bypass!
HDBT OUT
RS-232 not connect
to HDBT OUT
receiver device COM
s device baud
port setting
57600 size 8
baudrate: 57600
stop 1 parity
data size :8, stop:1
none!
parity: none
send RS-232
s rs232 time
command wait time
200!
200ms
-11-
Feedback Default Setting
y=0
200ms
