Comfy Go Mobility X-6 User Manual page 11

3. Usage and Operation
3.1 Wheelchair Adjustments
Folding Your Wheelchair
Step 1: Take off the battery and unplug the red plug. (Picture 1).
Step 2: Pull the joint switch backward and pull back on the handle
(Picture 2 and 3).
Step 3: Pull the cushion up by hand and fold the wheelchair (Picture 4).
Picture 1
Unfolding Your Wheelchair
When the wheelchair is partially apart, lift up both side handles until
you hear a clicking sound, and check handle to make sure it's secured
in place.
Connect Wire Line
Connect the battery box plug into the control plug (Picture 5).
Adjustment of Joystick
Loosen the quick release spanner which is under the armrest
(Picture 6). Adjust the controller to the proper position, rotate the
spanner clockwise then secure it in place. After securing the control-
ler, place the control wire into the groove.
Picture 2
Picture 5
10
Picture 3
Picture 6
Picture 4
