Installation Manual
Color LCD Monitor
Important
Please read this "Installation Manual", and "Instructions for Use"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Refer to the "Instructions for Use" for information on the
installation / connection of the monitor. The "Installation Manual" is
part of the "Instructions for Use".
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo CuratOR EX4342
Summary of Contents for Eizo CuratOR EX4342
- Page 1 Installation Manual Color LCD Monitor Important Please read this “Installation Manual”, and “Instructions for Use” (separate volume) carefully to familiarize yourself with safe and effective usage. • Refer to the “Instructions for Use” for information on the installation / connection of the monitor. The “Installation Manual” is part of the “Instructions for Use”.
- Page 2 EIZO GmbH. EIZO GmbH is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO GmbH’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.
-
Page 3: Table Of Contents
CONTENTS CONTENTS ............. 3 Chapter 1 Basic Adjustment / Setting ....4 1-1. Loading the Monitor Settings ...... 4 ● Saving current settings to “User1” through ”User5” ..........5 1-2. Switching Input Signals ....... 5 1-3. Using Custom Keys ........6 ●... -
Page 4: Chapter 1 Basic Adjustment / Setting
Chapter 1 Basic Adjustment / Setting This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front of the monitor. 1-1. Loading the Monitor Settings Basic settings are made in advance at the factory. It is possible to switch to the following preset settings that have been set in advance. -
Page 5: Saving Current Settings To "User1" Through "User5
● Saving current settings to “User1” through ”User5” You can save the current setting values and display status to “User1” through ”User5”. Press MENU. The Setting menu appears. Press F3/Down or F4/Up to select “Preferences”, and then press ENTER. The “Preferences” menu appears. Press F3/Down or F4/Up to select “PRESET Save”, and then press ENTER. -
Page 6: Using Custom Keys
1-3. Using Custom Keys Execute the functions assigned to the custom keys (F1/Left, F2/Right, F3/Down and F4/Up). For information on how to set a function to each custom key, see “Setting a function to custom keys” (page Press F1/Left, F2/Right, F3/Down and F4/Up. The function associated with the custom key that is pressed will run. -
Page 7: Chapter 2 Advanced Adjustments / Settings
Chapter 2 Advanced Adjustments / Settings This chapter describes advanced monitor adjustments and settings procedures using the main menu. 2-1. Basic Operation of the Setting Menu Menu display 1. Press MENU. *The control panel key is located to the lower right on the back of the housing frame. - Page 8 Adjustments / Settings Pressing MENU during adjustment/setting will cancel the adjustment/setting and restore the state prior to making changes. 1. Press F3/Down or F4/Up to select a menu to adjust/set, and then press ENTER. The submenu appears. 2. Press F3/Down or F4/Up to select an item to adjust/set, and then press ENTER. The Adjustment/Setting menu appears.
-
Page 9: Setting Menu Functions
2-2. Setting Menu Functions ● Color Function Settings Description Active PbyP Left Window / Select which window to adjust settings when dual screen display (PbyP Window Right Window or PinP). PinP Large Window / Note Small Window • For dual screen display (PbyP or PinP), color adjustment can be Single All performed for each screen selected in “Active Window”. -
Page 10: Signal
● Signal Function Settings Description Active (When single screen display mode.) Select which window to adjust settings when dual screen Window display (PbyP or PinP). (When “Multi Window” is set to “PbyP”.) Left Window / Right Window (When “Multi Window” is set to “PinP”.) Large Window / Small Window Input Color... -
Page 11: Preferences
● Preferences Function Settings Description Multi Window Single / PbyP / PinP Select single screen display or dual screen display (PbyP or PinP). • “Single” Display selected input signal on the screen. • “PbyP” Display two different signals side-by-side on one screen simultaneously. - Page 12 Function Settings Description Advanced Auto Input On / Off This function automatically recognizes the Settings Detection connector through which computer signals are input, and displays images on the screen accordingly. • “On” When the monitor is connected to multiple computers, if a specific computer enters power saving mode or no signals are input to the monitor, the connector is automatically changed to another one to which signals are...
-
Page 13: Information
● Information Display the monitor information (model name, serial number (S/N), usage time) and the input signal information. Example: ● PbyP If you press INPUT while in PbyP dual screen mode, the “PbyP” menu is displayed. Function Setting Description Left Window DisplayPort / HDMI / SDI 1 / Select the signal input to the left window when PbyP dual screen SDI 2 / DVI... -
Page 14: Pinp
● PinP If you press INPUT while in PinP dual screen mode, the “PinP” menu is displayed. Function Setting Description Large Window DisplayPort / HDMI / SDI 1 / Select the signal input to the large window when PinP dual SDI 2 / DVI screen display. -
Page 15: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting 3-1. No Picture Displayed Problem Possible cause and remedy 1. No picture. • Check whether the power cord is connected properly. • Check whether the DC OUT terminal and the DC IN terminal are connected properly. • Turn on the power switch. •... -
Page 16: Imaging Problems
3-2. Imaging Problems Problem Possible cause and remedy 1. The screen is too bright or too dark. • Use “Brightness” or “Backlight” in the Setting menu to adjust 2. Text is blurred • Check whether the computer is configured to meet the resolution and vertical scan frequency requirements of the monitor (see “Displayable Input Signals”... -
Page 17: Chapter 4 Reference
Chapter 4 Reference 4-1. Main Default Settings Preset Default Item DisplayPort DisplayPort HDMI SDI [BT.2020] [sRGB] [BT.2020] [BT.2020] MAIN DisplayPort DisplayPort HDMI SDI 1 (Left Window/Large Window) Input Port SDI 1 SDI 1 SDI 1 (Right Window/Small Window) Multi Window Single Single Single... -
Page 18: Pin Specifications
4-2. Pin Specifications ● DC IN terminal Pin No. Signal name 48 VDC 48 VDC ● DC OUT terminal on the main unit Pin No. Signal name 5 VDC 5 VDC HIROSE P/N: HR10A-7R-4S(74) Recommended plug HIROSE P/N: HR10A-7P-4P(74) ● DC OUT terminal of AC adapter Pin No. -
Page 19: Appendix
United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorEdge Tablet Controller, ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO Monitor Configurator, EIZO ScreenSlicer, G-Ignition, i•Sound, Quick Color Match, RadiLight, Re/Vue, SafeGuard, Screen... -
Page 20: Limited Warranty
In repairing the Product, EIZO and Distributors will use renewal parts which comply with our QC standards. If the unit cannot be repaired due to its condition or the stockout of a relevant part, EIZO and Distributors may offer the replacement by a product with equivalent performance instead of repairing it. -
Page 21: Recycling Information
Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una filial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. www.eizoglobal.com... - Page 22 Este produto, quando o deitar fora, deve ser recolhido e reciclado de acordo com a legislação do seu país para reduzir a poluição. Quando deitar fora este produto, contacte um distribuidor ou uma filial no seu país. Os endereços de contacto estão listados no website do EIZO, abaixo. www.eizoglobal.com...
- Page 23 страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
- Page 24 Geri Dönüşüm Bilgisi Bu ürünün, atılacağı zaman, ülkenizin çevre kirliliğinin azaltılması konusundaki mevzuatına göre toplanması ve yeniden değerlendirilmesi gerekmektedir. Ürünü atacağınız zaman lütfen ülkenizdeki bir distribütör veya ilgili kuruluşla temasa geçiniz. İrtibat adresleri aşağıdaki EIZO web sitesinde verilmiştir. www.eizoglobal.com Appendix...
- Page 25 CuratOR EX4342 Installation Manual Carl-Benz-Straße 3, 76761 Rülzheim, Germany 1086012-001 Copyright © 2022 EIZO GmbH. All rights reserved. 1st Edition - February, 2022...
