Instructions for Use
Color LCD Monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For monitor adjustment and settings, refer to the "Installation
Manual".
Advertisement
Table of Contents
Related Manuals for Eizo CuratOR EX3241
Summary of Contents for Eizo CuratOR EX3241
- Page 1 Instructions for Use Color LCD Monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For monitor adjustment and settings, refer to the “Installation Manual”.
- Page 2 EIZO Corporation is under no obligation to keep any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To ensure personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. - Page 4 If the unit is installed incorrectly, it may drop or fall over, resulting in personal injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 5 WARNING To disconnect the power cord or adapter power cable, grasp the plug firmly and pull. Tugging on the cord or cable may damage it and result in fire or electric shock. The equipment must be connected to a grounded main outlet. Failure to do so may result in fire or electric shock.
- Page 6 CAUTION Check the operational state before use. • Before starting to use the monitor, please make sure that there are no problems with the displayed image. • When using multiple units, please make sure that the images are displayed appropriately. Securely fix cables / cords that have a fixing feature.
- Page 7 CAUTION Unplug the unit before cleaning it. Cleaning the unit while it is plugged into a power outlet may result in electric shock. If you plan to leave the unit unused for an extended period of time, disconnect the power plug from the wall socket after turning off the power switch for safety and power conservation.
-
Page 8: About The Monitor
• The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The screen may have defective pixels or a small number of light dots on the screen. This is due to the characteristics of the panel itself, and is not a malfunction of the product. -
Page 9: Cleaning
Cleaning Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. Gently wipe off any dirt on the cabinet or panel surface with a soft cloth soaked in a small amount of water or one of the chemicals listed below. Chemicals that may be used for cleaning Material name Product name... -
Page 10: Table Of Contents
CONTENTS PRECAUTIONS ............3 IMPORTANT .............. 3 About the monitor ..........8 Intended Use ............. 8 Precautions for Use ..........8 Cleaning ..............9 CONTENTS ............10 Chapter 1 Introduction ........11 1-1. Features ............11 1-2. Package Contents ........12 1-3. Controls and Functions ......12 Chapter 2 Installation / Connection .... -
Page 11: Chapter 1 Introduction
Chapter 1 Introduction 1-1. Features ● High-quality and high-resolution Ultra High Definition (UHD) • The UHD LCD display allows for display of high-quality, high-resolution medical images. • Equipped with front protection panel • LED Backlight • Optical bonding for high visibility ●... -
Page 12: Package Contents
1-2. Package Contents Check that all of the following items are included in the package. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport this product. •... - Page 13 Front Bottom View Displays the preset menu. (PRESET) button Displays the input select menu. (INPUT) button Displays the main menu. (MENU) button Executes the function assigned to this button. Select items in the menu screen. (F1) button (F2) button (F3) button (F4) button Executes the function assigned to this button.
- Page 14 Rear 12G-SDI 3G-SDI DVI-D 1 DVI-D 2 DisplayPort HDMI RS-232C 11. DC IN terminal Connects the DC OUT terminal of the AC adapter. 12. DC OUT terminal Used when providing 5V power to a peripheral device. Attention • Do not connect this to the terminal to measurement devices or medical equipment which will come into contact with a patient.
-
Page 15: Chapter 2 Installation / Connection
Chapter 2 Installation / Connection 2-1. Before Installing the Product Carefully read “PRECAUTIONS” (page 3) and always follow the instructions. When installing this product, perform thorough operational testing (of the system, cables, arms, etc.) in the environment where the product will be used. ●... -
Page 16: Installing The Product
2-2. Installing the Product This product should be installed using an arm or stand. Attention • When installing, do so by carefully following the information in the User Manual about the arm or stand. • Ensure the following and select components that comply with the VESA standards. - Clearance between the screw holes: 100 mm ×... - Page 17 Using the supplied screws Thickness of installation fixture 2 mm - 4.5 mm (M4 screw / M6 screw) Cabinet Installation fixture Screw supplied with the monitor Using commercially available screws Installation fixture Cabinet Effective length 7 mm - 11 mm (M4 screw) 7 mm - 12 mm (M6 screw) Commercially available screw Chapter 2 Installation / Connection...
-
Page 18: Connecting The Power Cord
2-3. Connecting the Power Cord Attention • Turn off the monitor before connecting it. • When removing the power cord, always remove the power plug from the power outlet first. Connect the power cord to the AC IN terminal on the AC adapter. Insert the power cord all the way to the back. -
Page 19: Connecting The Cables
2-4. Connecting the Cables Connect the cables appropriate for the device to be used. If you connected the HDMI cable to the monitor, be sure to secure the HDMI cable with the HDMI cable holder. 1. Turn the lever of the HDMI cable holder downward. 2. -
Page 20: Installing The Cable Cover
2-5. Installing the Cable Cover Align the cable cover on the back of the monitor in such a way that the cables can go through the cable outlet port. Insert the cable cover tabs into the grooves in the monitor. Tighten the screws at the left and right-hand holes on the bottom side of the monitor. -
Page 21: Chapter 3 If No Image Is Displayed
Chapter 3 If No Image Is Displayed Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Check whether the DC OUT terminal and DC IN terminal are connected properly. • Turn on the power switch. •... -
Page 22: Chapter 4 Specifications
Chapter 4 Specifications 4-1. Specifications List Monitor LCD Panel Type Color (IPS) Backlight Size 81.3 cm (32.0 inch) Display resolution (H x V) 3840 × 2160 Display Size (H x V) 708.5 mm × 398.5 mm Pixel Pitch 0.185 mm × 0.185 mm Display Colors 8-bit: 16.77 million colors 10-bit (SDI / DisplayPort / HDMI): 1073.74 million colors (Max.) - Page 23 Physical Specifications External dimensions 760 mm × 463 mm × 87 mm (W × H × D) Net Weight Approx. 12.8 kg Protection structure IP32 (The IPx2 protection level is effective when the monitor is installed so it cannot be put at a slant.) Operating Environmental Requirements Temperature 0 ˚C to 35 ˚C (32 ˚F to 95 ˚F)
-
Page 24: Displayable Input Signals
4-2. Displayable Input Signals √: Supported Horizontal Vertical SDI 1 DVI-D 1 Signal name Frequency Frequency DisplayPort HDMI SDI 2 DVI-D 2 (kHz) (Hz) 720 x 480@59p 31.469 59.940 √ √ 720 x 480@60p 31.500 60.000 √ √ 720 x 576@50p 31.250 50.000 √... -
Page 25: Appendix
Appendix Medical Standard • It is necessary to ensure that the final system is in compliance with IEC60601-1-1 requirements. • Power-supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, in which such effects are avoided. -
Page 26: Emc Information
EMC Information The performance of the EX3241 ensures appropriate display of images. Intended Use Environments The EX3241 is intended to be used in professional healthcare facility environments such as clinics and hospitals (including use in the vicinity of high-frequency surgical equipment such as electrosurgical knives). - Page 27 Technical Specifications Electromagnetic emissions The EX3241 is intended for use in the electromagnetic environment specified below. The customer or the user of the EX3241 should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions Group 1 The EX3241 uses RF energy only for its internal function.
- Page 28 Electromagnetic immunity The EX3241 has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the EX3241 must ensure that the EX3241 is used in the following environments: Immunity test Test level for Compliance level...
- Page 29 Recommended separation distances between portable or mobile RF communication equipment and the EX3241 The EX3241 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EX3241 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EX3241.
-
Page 30: Warning For Radio Interference
Trade name: EIZO declare that the product Model: CuratOR EX3241 is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 31 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan 中国苏州市苏州工业园区展业路 8 号中新科技工业坊 5B Siemensallee 84, 76187 Karlsruhe, Germany 00N0N101A1 www.eizoglobal.com IFU-EX3241-6 Copyright © 2019 EIZO Corporation. All rights reserved. 1st Edition-February, 2019 Printed in Japan.
