Spacerails Level 3 Instruction Booklet page 5

1
PREPARE THE COASTER COMPONENTS
A
BASE ASSEMBLY
Step 1: Interlock 6 Base blocks at tabs
as shown below. Be sure tabs connect.
Step 2: Press 2 Base Holder A and
2 Base Holder B pieces into the
Base blocks as shown below to
secure the Base blocks in place.
Base Holder B
B
ARMS
(QTY: 40)
Step 1: Attach one Arm Holder A and one
Arm Holder B with one Arm Sheath. Insert
one Arm Clip into Arm Holder A.
To avoid damaging parts, do not move or adjust the Rail Clip while locked in the arm. To move the Rail Clip,
release Arm Lock by turning clockwise, position Rail Clip as desired, then secure Arm Lock again.
C
RAIL SPLITTER
Seaich Corporation, LLC. All rights reserved. www.seaich.com | Spacerails, LLC. www.spacerails.com
Base Holder A
Make sure Base
Blocks connect
at tabs.
Step 2: Insert Arm Lock through
Arm Holder A and Arm Clip.
Base Blocks x6
Step 3: Turn the Arm Lock
counter-clockwise to secure
the Arm Clip in place.
Prepare Rail Splitter: Attach one Rail
Clip to each of the 3 Rail Splitter posts
(3 total Rail Clips).
Base Holder B
Page 5
