Operation and Interface
This section will show you the basic operation and interfaces of the web user interface for your camera.
Live
This section of the manual details the camera's interface, as well as all the operations the camera can perform.
The live view tab allows the user to see a live video feed from the camera. The live view tab has five main sections:
Section 1: This bar allows the user to switch between mainstream and substream resolutions.
Section 2: The functions bar allows the user to perform different camera functions while in live mode. See the
table below for an explanation of the different functions available:
Button
Function Name
Snapshot
Audio
Section 3: This is the live feed from your camera.
Section 4: This section of the Live tab shows the PTZ functionality of the camera. Use the directional arrows to
pan/tilt your camera
Section 5: This button allows the user to show or hide the pan tilt control panel on the live view screen.
Please note, due to hardware limitations, the IP2M-841-V3 does not have zoom capabilities.
Function Description
Click this button to take a screenshot of the live feed.
Click this button to enable or disable audio output from the camera.
This feature allows the user to listen in on the audio the camera's
microphone is picking up.
16
