Icom IC-V8 Instruction Manual page 19

q CONTROL DIAL [VOL]
Rotate to adjust the volume level.*
w POWER SWITCH [POWER]
Push for 1 sec. to turn the power ON and OFF.
e PTT SWITCH [PTT]
Push and hold to transmit; release to receive.
r SQUELCH SWITCH [SQL]
Push and hold to force the squelch open and set the transceiver
to the squelch level adjustable condition.
t UP/DOWN KEYS [Y]/[Z]*
Selects the operating frequency.*
y KEY PAD (pgs. 4–6)
Used to enter operating frequency, the DTMF codes, etc.
u ANTENNA CONNECTOR
Connects the supplied antenna.
i [SP]/[MIC] JACK
Connect an optional speaker-microphone or headset, if desired.
The internal microphone and speaker will not function when ei-
ther is connected.
o FUNCTION DISPLAY (pgs 7, 8)
*The assigned function for [VOL] and [Y]/[Z] can be traded in
INITIAL SET MODE
(pgs. 17, 53).
PANEL DESCRIPTION
