Icom IC-F11BR Instruction Manual page 15

D Rapid charging with the BC-144+AD-99
BP-209, BP-210
or BP-222 attached
to the transceiver.
AC adaptor
BC-145A/E/V/UK
Charging indicator
D D Spacer combination.
• Be sure to attach the
spacer (Spacer B/C) to
the adapter (Spacer A)
with the orientation as il-
lustrated in the diagram at
right.
• Attach the
(Spacer B/C) to the adap-
tor with the orientation of the stamp "
NOTE: Push the notch carefully
when removing the spacer from the
adaptor.
Spacer A
spacer
BATTERY PACKS
Turn power OFF
Check
and the spacer com-
bination as follows.
Check orientation
Spacer B/C
" pointing up.
3
orientation
and
3
8
