Structure Diagram

8.
PS/2 keyboard
Aluminium front panel
Class A active matrix TFT LCD panel
Rear metal case
Analog to digital signal converter board
LCD inverter
LCD membrane
Ball bearing telescopic slides
Adjustable mounting bracket
Optional KVM membrane & KVM switch board
