- Page 1 User Manual RKP115 / 117 / 119 – 801/1601 1U 15” / 17” / 19” LCD Keyboard Drawer with PS/2 KVM...
-
Page 3: Table Of Contents
RKP115 / RKP117 / RKP119 Table of Content Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram Dimension Diagram RKP115-8/1601 RKP117-8/1601 RKP119-8/1601 10. LCD Session LCD Membrane Diagram LCD OSD Control Resolution Settings 11. KVM Session Front View Rear View Installation Steps Cascading... -
Page 4: Introduction
RKP115 / RKP117 / RKP119 RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. RKP Series provides cost effective for your limited IT budget over using CRT and rack mounting. -
Page 5: Package Contents
RKP115 / RKP117 / RKP119 LCD Monitor Drawer with PS/2 KVM Switch User Manual DC Power Adapter Power Cord Mounting Bracket Fasteners CD-6 3-in-1 KVM cable Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. The surface for placing and fixing the LCD Keyboard Drawer should be stable and level ●... -
Page 6: Optional Accessories
RKP115 / RKP117 / RKP119 KVM Cable CD-6 / 10 / 15 Cascade Cable CA-2 / 6 / 10 / 15 Conversion Adapter SUN-31 Others Model CV-401 CV-801 CV-1601 CV-101 Rev. : 1.0 Optional Accessories 6ft / 10ft / 15ft PS/2 3-in-1 cable 2ft / 6ft / 10ft / 15ft PS/2 3-to-3 cable SUN / iMAC USB to PS/2 adapter Video Input... -
Page 7: Important Safeguards
RKP115 / RKP117 / RKP119 Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 8: Structure Diagram
RKP115 / RKP117 / RKP119 PS/2 keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case LCD inverter LCD membrane Ball bearing telescopic slides with stopper Adjustable mounting bracket Optional KVM switch Rev. : 1.0 Structure Diagram •... -
Page 9: Dimension Diagram
RKP115 / RKP117 / RKP119 User Manual Dimension Diagram RKP115-8/1601 1U 15” LCD Keyboard Drawer with PS/2 KVM 15” LCD Rev. : 1.0... -
Page 10: Rkp117-8/1601
RKP115 / RKP117 / RKP119 User Manual Dimension Diagram RKP117-8/1601 1U 17” LCD Keyboard Drawer with PS/2 KVM 17” LCD Rev. : 1.0... -
Page 11: Rkp119-8/1601
RKP115 / RKP117 / RKP119 User Manual Dimension Diagram RKP119-8/1601 1U 19” LCD Keyboard Drawer with PS/2 KVM 19” LCD Rev. : 1.0... -
Page 12: Lcd Session
RKP115 / RKP117 / RKP119 User Manual Session Rev. : 1.0 P.10... -
Page 13: Lcd Membrane Diagram
RKP115 / RKP117 / RKP119 LCD Membrane Diagram Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ● An “ Adjusting” message is displayed during the process ●... - Page 14 RKP115 / RKP117 / RKP119 Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 15 RKP115 / RKP117 / RKP119 MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 16: Resolution Settings
RKP115 / RKP117 / RKP119 Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 LCD Session P.14 User Manual... -
Page 17: For Sun Servers
RKP115 / RKP117 / RKP119 Resolution Settings For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ●... -
Page 18: Kvm Session
RKP115 / RKP117 / RKP119 User Manual Session Rev. : 1.0 P.16... -
Page 19: Front View
RKP115 / RKP117 / RKP119 Front View Online Channel LED Indication Selected Channel Channel select button - Press to select channel from 1 – 8. Shift button Online Channel Bank no. Bank button Rev. : 1.0 KVM Session Selected Channel Channel Select Button - Displayed channel on monitor &... -
Page 20: Rear View
RKP115 / RKP117 / RKP119 Rear View Power RKP11X-801 RKP11X-1601 DC Power Cascade Port Channel Port Rev. : 1.0 KVM Session Cascade Channel Port -connect to external 12V DC power adapter. -connect to additional KVM switch for channel expansion. -connect to PC computer with CD-6 3-in-1 KVM cable. P.18 Port User Manual... -
Page 21: Installation Steps
RKP115 / RKP117 / RKP119 Installation Steps Before installation, please make sure all of peripherals and computers have been turned off. Connect the 3-in-1cable with 2 mini-din 6-pin connectors and a HDDB 15-pin connector to the computer ports. Connect another end of the cable to KVM switch. Plug the power adapter included to the LCD Keyboard Drawer. -
Page 22: Cascading
RKP115 / RKP117 / RKP119 Cascading Using CA-6 PS/2 KVM cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the PS/2 KVM switch to reset the PS/2 KVM switch. Bank 1 Bank 2 Bank 8... -
Page 23: Start Up
RKP115 / RKP117 / RKP119 The channels that have PC connected and it is switch on will have a green LED on that channel. The red LED will indicate the selected channel. 7 segments LED will display the bank number. Press channel button to select the channel. -
Page 24: Hotkey Command Operation
RKP115 / RKP117 / RKP119 Hot-key Command Operation Calling OSD Menu Scroll Switch to Previous Port (powered on PC only) Scroll Switch to Next Power On Port (powered on PC only) Scroll Switch to Previous Bank Scroll Switch to Specific Port Scroll Example : Bank 1 Port 4... - Page 25 RKP115 / RKP117 / RKP119 HotKey Command Operation Switch to Next Bank Scroll Enable / Disable beeper sound Scroll Note: The default Beeper function is ON and beeper control is only for Auto Scan for Powered on PC Scroll Reset to factory Default Setting Scroll Note: Not available for password reset.
-
Page 26: Osd Structure Diagram
RKP115 / RKP117 / RKP119 OSD Structure Diagram BANK : 1 BANK : 1 ® SYSTEM 03 SYSTEM ® SYSTEM 03 ® SYSTEM 05 ® SYSTEM 05 SYSTEM 07 OSD : 1 0 SEC. CHANGE PASSWORD OSD : 1 0 SEC. CHANGE PASSWORD SCAN: 1 0 SEC. -
Page 27: Kvm Settings Session
RKP115 / RKP117 / RKP119 KVM Settings Session ● ● Scan ● ● Change Password ● ● ● ● ● ● ● Console On/OFF ● ● ● Escape ● Rev. : 1.0 Start Up OSD Menu on screen time default is 10 seconds. It can be modified from 05 –... -
Page 28: 13. Faq
RKP115 / RKP117 / RKP119 13. FAQ 1. Don’t press any keys on the keyboard while the selected computer is booting up. Otherwise, it might cause the keyboard error or keyboard is not detected at PC side. 2. The computer boot up fine, but keyboard doesn’t work. Make sure the keyboard works when directly plugged into the computer. -
Page 29: Technical Specification
RKP115 / RKP117 / RKP119 KVM Channel Port KVM Channel Interface PC Computer Interface Cascade Port Connector KVM Cable Connection PC selection On Screen Display Control Scan Mode Intervals VGA Resolution Bandwidth Cascade MAX. Level Housing Power Adapter Operation Temperature Storage Temperature Humidity Rev. - Page 30 RKP115 / RKP117 / RKP119 LCD Screen Manufacturer LCD Origin Panel Resolution Brightness Color Contrast Ratio Viewing Angle Display Area Pixel Pitch Response Time (Tr) Response Time (Tf) Back Light Horizontal Sync. Vertical Sync. Input Signal Power Management OSD Control Power Input Video Input Dimension...
