Summary of Contents for I-Tech RKP1615
- Page 1 User Manual RKP1615 / 1617 / 1619 1U 15” / 17” / 19” Rackmount TFT LCD Monitor Keyboard Drawer...
-
Page 2: Table Of Contents
RKP1615 / RKP1617 / RKP1619 Table of Content Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram Dimension Diagram 10. LCD OSD Menu Operation 11. Resolution Settings 12. Technical Specification Rev. : 1.0 Table Of Content RKP1615... -
Page 3: Introduction
RKP1615 / RKP1617 / RKP1619 RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. -
Page 4: Package Contents
RKP1615 / RKP1617 / RKP1619 LCD Monitor User Manual DC Power Adapter Power Cord Mounting Bracket Key for Front Access Lock Fasteners CD-6 3-in-1 KVM cable Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. -
Page 5: Optional Accessories
RKP1615 / RKP1617 / RKP1619 Video Input 12V / 24V / 48V DC Power SUN-31 Model CV-401 / CV-801 / CV-1601 CV-1602 CV-S801 / CV-S1601 CV-S1602 CV-101 Rev. : 1.0 Optional Accessories SUN / iMac USB to PS/2 Adapter Peripheral Products... -
Page 6: Important Safeguards
RKP1615 / RKP1617 / RKP1619 Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 7: Structure Diagram
RKP1615 / RKP1617 / RKP1619 PS/2 keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case Analog to digital signal converter board LCD inverter LCD membrane Adjustable mounting bracket Rev. : 1.0 Structure Diagram ‚ ƒ „... -
Page 8: Dimension Diagram
RKP1615 / RKP1617 / RKP1619 User Manual Dimension Diagram RKP1615 1U 15” LCD Keyboard Drawer 15” LCD Rev. : 1.0... -
Page 9: Rkp1617
RKP1615 / RKP1617 / RKP1619 User Manual Dimension Diagram RKP1617 1U 17” LCD Keyboard Drawer 17” LCD Rev. : 1.0... -
Page 10: Rkp1619
RKP1615 / RKP1617 / RKP1619 User Manual Dimension Diagram RKP1619 1U 19” LCD Keyboard Drawer 19” LCD Rev. : 1.0... -
Page 11: Lcd Osd Menu Operation
RKP1615 / RKP1617 / RKP1619 LCD Membrane Diagram Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ● An “ Adjusting” message is displayed during the process ●... - Page 12 RKP1615 / RKP1617 / RKP1619 Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 13 RKP1615 / RKP1617 / RKP1619 MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 14: Resolution Settings
RKP1615 / RKP1617 / RKP1619 For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 Resolution Settings P.13... -
Page 15: For Sun Servers
RKP1615 / RKP1617 / RKP1619 For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ● 1024 x 768 x 70/75Hz ●... -
Page 16: Technical Specification
12V DC Adapter 15-pin D-Sub Connector RKP1615 / 1617 : 44.2W x 4.45H x 65D cm RKP1619 : 44.2W x 4.45H x 67D cm RKP1615 : 19kg / RKP1617 : 20kg / RKP1619 : 22kg P.15 Description 15” TFT South Korea 17”...
