I-Tech RKP1015 Specifications

1U
Rack mount Dual Slides 15" TFT LCD monitor keyboard drawer / KVM switch
Model: RKP 1015,
RKP1015-801& RKP1015-1601
Monitor Features:
l
Unique mechanical design to maximize rack
mountable space
l
Unique monitor flip up design allows viewing
through closed glass door of cabinet
l
Adjustable mounting brackets from 15.4" to
31.1" (390 to 790 mm) (front to rear 19" mounts).
Suitable for 30" to 39.4"(750 to 1000mm) deep
19"cabinet
l
Keyboard with GlidePoint touch pad mouse
l
Built-in on screen display controlled by integral
membrane switches
l
Standard D-sub 15-pin VGA input connector
l
Supplied with 12V 5A remote power adapter
l
All mounting hardware included
Specification
Monitor
Panel: 15" LCD panel
Display type: TFT / LCD active matrix color
Resolutions: 1024 x 768
Response time: Tr=5ms/ Tf=20ms
Contrast ratio: 300 : 1 typical
Brightness: 250 cd/m
Pixel pitch: 0.297mm (H) x 0.297mm (W)
Panel color: 16.7 million display colors
Viewing angle: 130
Storage temp. -25
Operating temp. 0
MTBF 35,000 hours
Power supply
Remote adapter:
Adapter Size:
Cable length from mains plug to adapter:
Cable length from adapter to unit:
Safety approval:
Mains plug options available
KVM
Computer connectors: 8/16
Connector: 15-pin HDB type, Keyboard, mouse, all-in-1
Cascade level: 8
Max. access PCs: 128
Input VGA resolution: 1,920 x 1,440
Weight
Model No KVM
RKP1015e Non
RKP1015-801e 8
RKP1015-1601e 16
Keyboard Selection:
1: Notebook type keyboard with touch pad mouse
Product dimension
--- 17.3"(W) x 1.75"(H) x 25.6"(D) (439x4.45x650mm)
Packing dimension
--- 28.96"(L) x 22.66"(W) x 7"(H) (735x575x180mm)
Construction
1. Class A active matrix TFT LCD
panel
2. Rear metal case
3. 8 or 16-port KVM control board
4. Adjustable mounting bracket
5. Analog-to-digital signal
converter board
www.i-techcompany.com,
2
typical
o o
(Horiz.)/ 110 (Vert.)
o o
C to 60 C
o o
C to 50 C
110V – 220V AC Input 12V 5A Output
4.3"(L) x 2.4" (W) x 1.2"(H) (108x61x30mm)
6ft (180cm)
6ft (180cm )
UL, CE
Net/ Gross weight
22.0 lbs / 39.6lbs(10 kg/18kg)
24.2 lbs / 44.0 lbs(11kg/20kg)
26.4 lbs / 46.2 lbs(12kg/21kg)
6. Inverter
7. Ball bearing telescopic slides
8. 8-push-button channel selector
switches
9. Front cover
10. Panel button control
11. Front metal case
Toll Free: 1-888-itech-18 (1-888-483-2418), Fax: 1-510-372-2736
With KVM Features only:
l
Multi-platform-mix PCs, SUNs, IBMs, HPs,
Compaq & DELL
l
Support 8 characters password protection &
search PC server name
l
Cascades for use with up to 128 servers
l
New keep alive feature safeguards server for power
loss to the switch
l
Built-in microprocessor emulation for each port
boots up process
l
Auto scan-mode for monitoring your servers at
intervals 5 to 99s
l
Hot-pluggable when adding or removing PC w/o
powering down the switch
l
Name you server up to 16 characters long
l
Supplied w/12V 1A remote power adapter(single
power source)
l
Supplied with 8 screened cables 6ft long
l
No software needed & all mounting hardware
included
1.75" / 44mm
1U
25.61"/650mm
25.61"/650mm
KVM membrane Controller
KVM Switches
