NVP1015 / NVP1017
8. Structure Diagram
1.
2.
3.
4.
5.
Analog to digital signal converter board
6.
7.
8.
Ball bearing telescopic slides with stopper
9.
Adjustable mounting bracket
10.
KVM membrane & KVM switch board
PS/2 keyboard
Aluminium front panel
Class A active matrix TFT LCD panel
Rear metal case
LCD inverter
LCD membrane
