I-Tech RKP117 Specifications

1U
Rack mount high bright 17" TFT LCD monitor keyboard drawer / KVM switch
RKP 117, RKP117-801
RKP117-1601
Features:
Unique mechanical design to
maximize rack mountable space
Black anodized aluminum front panel
Adjustable mounting brackets from
15.4" to 31.1" (390 to 790 mm) (front to
rear 19" mounts). Suitable for 30" to
39.4"(750 to 1000mm) deep 19"cabinet
Keyboard with GlidePoint touch pad
mouse
Built-in on screen display controlled
by integral membrane switches
Standard D-sub 15-pin VGA input
connector
Supplied with 12V 5A remote power
adapter
All mounting hardware includ
Specification
Monitor
Panel: 17" LCD panel
Display type: TFT / LCD active matrix color
Resolutions: 1280 x 1024
Response time: Tr=5ms/ Tf=20ms
Contrast ratio: 350 : 1 typical
Brightness: 250 cd/m2 typical
Pixel pitch: 0.264mm (H) x 0.264mm (W)
Panel color: 16.7 million display colors
o
Viewing angle: 150 (Horiz.)/ 125
o
Storage temp. -25
o
Operating temp. 0 C to 50
MTBF 20,000 hours
KVM
Computer connectors: 8/16
Connector: 15-pin HDB type, Keyboard, mouse, all-in-1
Cascade level: 8
Max. access PCs: 128
Input VGA resolution: 1,920 x 1,440

Power supply

Remote adapter:
Adapter Size:
Cable length from mains plug to adapter:
Cable length from adapter to unit:
Safety approval:
Mains plug options available
Product dimension
--- 17.3"(W) x 1.75"(H) x 23.64"(D) (439x44.5x600mm)
Packing dimension
--- 28.96"(L) x 22.66"(W) x 7"(H) (735x575x180mm)
Weight
Model No KVM
RKP1017 Non
RKP1017-801 8 port
RJP1017-1601 16 port
Construction
1. Class A active matrix TFT LCD panel
2. Rear metal case
3. 8 or 16-port KVM control board
4. Adjustable mounting bracket
5. Analog-to-digital signal converter board
6. Inverter
7. Ball bearing telescopic slides
8. 8-push-button channel selector switches
9. Front cover
10. Panel button control
11.
Front metal case
www.i-techcompany.com,
o
(Vert.)
o
C to 60 C
o
C
110V - 220V AC Input 12V 5A Output
4.3"(L) x 2.4" (W) x 1.2"(H) (108x61x30mm)
6ft (182cm)
6ft (180cm )
UL, CE
Net / Gross weight
24.2 lbs/ 41.8lbs (11kg/19kg)
26.4lbs/ 46.2lbs (12kg/21kg)
28.6lbs / 48.4lbs ( 13kg/22kg)
Toll Free: 1-888-itech-1u (1-888-483-2418), Fax: 1-510-372-2736
With KVM Features only:
Multi-platform-mix PCs, SUNs, IBMs, HPs, Compaq &
DELL
Support 8 characters password protection & search PC
server name
Cascades for use with up to 128 servers
New keep alive feature safeguards server for power loss
to the switch
Built-in microprocessor emulation for each port boots
up process
Auto scan-mode for monitoring your servers at intervals
5 to 99s
Hot-pluggable when adding or removing PC w/o
powering down the switch
Name you server up to 16 characters long
Supplied w/12V 1A remote power adapter(single power
source)
Supplied with 8 screened cables 6ft long
No software needed & all mounting hardware
included
