- Page 1 User Manual RKP1015 / 1017 1U 15” / 17” TFT LCD Monitor Keyboard Drawer...
-
Page 2: Table Of Contents
RKP1015 / RKP1017 Table of Content Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram Dimension Diagram 10. LCD OSD Menu Operation 11. Resolution Settings 12. Technical Specification Rev. : 1.0 Table Of Content RKP1015 RKP1017 LCD Membrane Diagram... -
Page 3: Introduction
RKP1015 / RKP1017 RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. RKP Series provides cost effective for your limited IT budget over using CRT and rack mounting. -
Page 4: Package Contents
RKP1015 / RKP1017 LCD Monitor User Manual DC Power Adapter Power Cord Mounting Bracket Fasteners CD-6 3-in-1 KVM cable Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or ●... -
Page 5: Optional Accessories
RKP1015 / RKP1017 Video Input 12V / 24V / 48V DC Power SUN-31 Model CV-401 / CV-801 / CV-1601 CV-1602 CV-S801 / CV-S1601 CV-S1602 CV-101 Rev. : 1.0 Optional Accessories SUN / iMac USB to PS/2 Adapter Peripheral Products Description... -
Page 6: Important Safeguards
RKP1015 / RKP1017 Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 7: Structure Diagram
RKP1015 / RKP1017 PS/2 keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case Analog to digital signal converter board LCD inverter LCD membrane Ball bearing telescopic slides Adjustable mounting bracket Optional KVM membrane & KVM switch board Rev. -
Page 8: Dimension Diagram
RKP1015 / RKP1017 User Manual Dimension Diagram RKP1015 1U 15” LCD Keyboard Drawer 15” LCD Rev. : 1.0... -
Page 9: Rkp1017
RKP1015 / RKP1017 User Manual Dimension Diagram RKP1017 1U 17” LCD Keyboard Drawer 17” LCD Rev. : 1.0... -
Page 10: Lcd Osd Menu Operation
RKP1015 / RKP1017 LCD Membrane Diagram Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ● An “ Adjusting” message is displayed during the process ●... - Page 11 RKP1015 / RKP1017 Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 12 RKP1015 / RKP1017 MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 13: Resolution Settings
RKP1015 / RKP1017 For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 Resolution Settings P.12... -
Page 14: For Sun Servers
RKP1015 / RKP1017 For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ● 1024 x 768 x 70/75Hz ●... -
Page 15: Technical Specification
