- Page 1 User Manual RKP115 / 117 / 119 1U 15” / 17” / 19” Rackmount TFT LCD Keyboard Drawer...
-
Page 2: Table Of Contents
RKP115 / RKP117 / RKP119 Table of Content Introduction Features Package Contents Optional Accessories Peripheral Products Important Safeguards Structure Diagram Dimension Diagram 10. LCD OSD Menu Operation 11. Resolution Settings 12. Technical Specification Rev. : 1.0 Table Of Content RKP115... -
Page 3: Introduction
RKP115 / RKP117 / RKP119 RKP Series is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. -
Page 4: Package Contents
RKP115 / RKP117 / RKP119 LCD Monitor User Manual DC Power Adapter Power Cord Mounting Bracket Fasteners CD-6 3-in-1 KVM cable Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet. -
Page 5: Optional Accessories
RKP115 / RKP117 / RKP119 Model SUN-31 Model CV-401 / CV-801 / CV-1601 CV-1602 CV-S801 / CV-S1601 CV-S1602 CV-101 Rev. : 1.0 Optional Accessories Description SUN / iMac USB to PS/2 adapter Video Input 12V / 24V / 48V DC Power Supply... -
Page 6: Important Safeguards
RKP115 / RKP117 / RKP119 Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 7: Structure Diagram
RKP115 / RKP117 / RKP119 PS/2 keyboard Aluminium front panel Class A active matrix TFT LCD panel Rear metal case LCD inverter LCD membrane Ball bearing telescopic slides with stopper Adjustable mounting bracket Optional KVM switch Rev. : 1.0 Structure Diagram •... -
Page 8: Dimension Diagram
RKP115 / RKP117 / RKP119 User Manual Dimension Diagram RKP115 1U 15” LCD Keyboard Drawer 15” LCD Rev. : 1.0... -
Page 9: Rkp117
RKP115 / RKP117 / RKP119 User Manual Dimension Diagram RKP117 1U 17” LCD Keyboard Drawer 17” LCD Rev. : 1.0... -
Page 10: Rkp119
RKP115 / RKP117 / RKP119 User Manual Dimension Diagram RKP119 1U 19” LCD Keyboard Drawer 19” LCD Rev. : 1.0... -
Page 11: Lcd Osd Menu Operation
RKP115 / RKP117 / RKP119 LCD Membrane Diagram Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ● An “ Adjusting” message is displayed during the process ●... - Page 12 RKP115 / RKP117 / RKP119 Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 13 RKP115 / RKP117 / RKP119 MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 14: Resolution Settings
RKP115 / RKP117 / RKP119 For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 Resolution Settings P.13... -
Page 15: For Sun Servers
RKP115 / RKP117 / RKP119 For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ● 1024 x 768 x 70/75Hz ●... -
Page 16: Technical Specification
Auto Config., Input Select, Multi-Window Clear EEPROM, OSD adjust 12V DC Adapter 15-pin D-Sub Connector RKP115/117 : 439W x 44H x 600D mm RKP119 : 439W x 44H x 650D mm RKP115 : 10.0kg RKP117 : 11.0kg RKP119 : 12.5kg P.15...
