Operating Temperature

The ambient operational temperature range is -45°C and
+85°C.
NOTE: The Handset will warm up in about 15 seconds at +20°C;
close to 1 minute at 0°C and up to 3 minutes at extreme cold
temperatures (-20 C) to be operational. It would be beneficial to
o
keep the Handset in a warm environment, before use.

Battery Voltage

The vehicle battery supplies power to the ECU, which in
turn powers the Handset.
For the 12V ALCOLOCK GR system, the vehicle battery
voltage can range from 9V - 18V. For a 24V ALCOLOCK
GR system, the vehicle battery voltage can range from
16V - 36V.

Handset Configuration

There are two versions of the Handset, a wired version
and a wireless version. The Handset can have either a
wired or wireless connection with the ECU. The Handset
uses a single navigation button to scroll up, down, right
and left. Pressing the centre of the navigation button
(Enter) selects the desired options.

Handset Cable

The Handset cable connects the wired version of the
Handset to the ECU, which in turn is connected to the
vehicle's ignition. The Handset should remain connected
at all times, but follow these steps if the Handset needs
to be removed.
