  • Page 1 OmniTT/AnesthesiaTT Installation and Service Guide 67-2024 Rev D...
  • Page 2 This guide and accompanying software and/or hardware described in it are protected under copyright laws and may not be copied, wholly or in part, without the express written consent of Omnicell, Inc. The same proprietary and copyright notices must be attached to any permitted copies as were attached to the original documents.

  • Page 3: Table Of Contents

    ..............IN-1 © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 4 ............. FB-1 OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...

  • Page 5: Electronics Tray

    2. Remove the four outer screws that secure the LCD bezel to the cabinet. Use a Torx T10 screwdriver. Figure 1-1. Remove the Four Outer Screws 3. Remove the front bezel. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...

  • Page 6: Remove The Lcd Assembly

    1. Perform a graceful shutdown of the electronics tray. 2. Open the console top. 3. Remove the speaker from the motherboard. Figure 1-3. Disconnect the speaker From the motherboard OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 7 1. Perform a graceful shutdown of the electronics tray. 2. Open the printer cover by pushing the black release mechanism toward the rear of the machine and lifting the cover. Figure 1-5. Open the Printer Cover © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 8 4. Remove the four screws (two on each side) that secure the printer assembly to the cover. Figure 1-7. Remove the Screws Securing the Printer Assembly 5. Remove the printer assembly. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 9 Figure 1-8. Remove the Screws that Secure the Lower Assembly 7. Disconnect the printer ribbon cable and the printer data cables from the printer board. Figure 1-9. Remove the Printer Ribbon Cable and the Printer Data Cable © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...

  • Page 10: Remove The Printer

    PC card to the frame. Figure 1-11. Remove the Screws that Secure the Printer PC Card 2. Lift the card off the frame slightly, then remove the printer ribbon cable. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.

  • Page 11: Remove The Keyboard

    Figure 1-12. Remove the nuts that secure the keyboard cover to the tray 2. Remove the keyboard cover. Figure 1-13. Remove the keyboard cover 3. Remove the keyboard from the tray. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...

  • Page 12: Replace The Keyboard

    3. Remove any bubble or ripples in the elastomer and then place the new keypad and elastomer back into place on the tray. Keyboard 1. Replace the keyboard cover. 2. Replace the screws that secure the keyboard cover to the tray. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 13 AUX cables from the rear of the TT cabinet. Figure 1-15. Location and labels for LAN and AUX cable connections on CT PC Tray 2. Access the electronics tray. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 14 Fan power cable (if applicable) Printer cable (free cable from any clips) j. Cabinet power/comm cable Figure 1-16. Location of cables on the CT PC Tray with PowerCom2 Board OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.

  • Page 15: Remove The Electronics Tray

    2. Turn the two 1/4-turn fasteners securing the electronics tray clockwise to lock the tray into place. Figure 1-18. Place the CT PC Tray into the Omnicell unit © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 16 Figure 1-20. Connect the Printer Cable to J27 of the Motherboard Note: Ensure that the red wire is connected closest to Pin 1. 3. Connect the fan power cable to J17 on the UPS board (if applicable). OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 17 Figure 1-21. Connect the Speaker Cable to J45 of the Motherboard 5. Connect the keyboard cable to port J42 on the motherboard. Figure 1-22. Connect the Keyboard Cable to J42 of the Motherboard © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 18 Figure 1-23. Connect the Touch Screen Data Cable to J2 of the Motherboard 7. Connect the inverter cable (backlight) to J32 on the motherboard. Figure 1-24. Connect the Backlight Cable to J32 of the Motherboard OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 19 Insert card reader power cable pins into the disk drive power connector. d. Align the red-stripe pin to the red cable and the gray-stripe pin to the gray cable in next spot. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 20 1-16 Electronics Tray Standardization Changes Standardization Changes To standardize the peripherals that Omnicell products use, the Seiko printer and PS/2 keyboards are being replaced by APS printers and USB keyboards with a numeric pad. The console swapped out in this procedure.

  • Page 21: Frames And Wireways

    Frames and Wireways Introduction The OmniTT/Anesthesia TT has a metal frame which houses the SPC boards and many of the cables that connect the components of the system. The frame is not field repairable and must be replaced if it is damaged. The wireway on the right side of any cabinet in an Omni TT is removable and the SPC board contained in the wireway is also replaceable.
  • Page 22 6. Push the transport handle toward the rear of the cabinet then remove it from the frame. Figure 2-3. Pull the transport handle toward the rear of the cabinet then remove it OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 23 6. Open the lid to the electronics tray. 7. Remove the thermal printer paper and spool. 8. Remove the electronics tray. For help, refer to “Electronics Tray” on page 1-9. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 24 10. Remove the bracket. 11. Remove the two screws that secure the manual override cable. Figure 2-6. Remove the two screws that secure the manual override cable to the frame OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 25 13. Remove the that secures the manual override cable to the front of the frame. Figure 2-8. Remove the nut that secures the manual override cable to the frame. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 26 3. Place the manual override cable into the frame anchor so that the two screws are on opposite side of the anchor bracket. 4. Tighten the screws. 5. Feed the front of the manual override cable through the hole on the front of the TT cabinet. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 27 11. Replace the electronics sled and reattach all cables that had been removed. 12. Close the lid to the electronics tray. 13. Feed the printer paper through the printer. 14. Power up the TT cabinet. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...

  • Page 28: Drawers

    The Omnicell Sensing Lid (OSL) models have sensing lids. As each lid is lifted, the system senses and records access to the bin. This guarantees security to those drawers that contain controlled substances.

  • Page 29: Matrix Drawers

    4. Use the gray circular labels provided with the kit to cover any un-used divider slots in the bin liner. Lit Matrix Drawers OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 30 The pipes provide support and help keep the dividers in place. Labels Numerical bin labels are provided with matrix drawers to make bin identification and restock easier for the customer. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 31 1. Perform a graceful shutdown of the TT cabinet. 2. Unlock the manual override cover. 3. Remove the cover by pushing it to the right and lifting it off. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 32 Figure 3-5. Connect the drawer controller cable to the controller board 9. Attach the slide to the slide support bracket with three screws washers using a Torx T15 screwdriver. 10. Install the slide support bracket. © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 33 16. Program the drawer at the OmniSupplier in OmniConfigurations. Removal Procedure 1. Perform a graceful shutdown of the CT PC box. 2. Remove the manual override cover. Figure 3-7. Remove the manual override cover OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 34 Figure 3-8. Pull the manual override lever 4. Remove the two screws securing the drawer controller cable cover to the cable clamps using a Torx T10 screwdriver. Figure 3-9. Remove the controller cable cover © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 35 Figure 3-11. Push the release levers to release the drawer Remove the pharmacy drawer from the module. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 36 2-1 frame 2-1 keyboard removal 1-7 replacement 1-8 LCD assembly 1-2 LCD screen 1-1 locking 3-1 sensing 3-1 manual override cable replacement 2-6 matrix drawers lit 3-3 unlit 3-2 © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...

  • Page 37: Appendix A: Part List

    KIT,DIVIDER,4/96,BIN,UNLIT,MTR Lit Matrix Drawers PowerCom3 CT PC Tray 15-9099 PowerCom 3 tray MFG ASSY, SLED, ELECTRONIC, PC3+ Installation Procedure 40-3001 (drawer) controller board PCB,ASSY,DRAWER,CONTROLLER Table A-1. TT Part List © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 38 Installation Procedure 53-7106 cable clamp CABLE,CLAMP,SLIDE,MOUNT,OMNIRX Removal Procedure 53-7112 release levers (on drawer) IR blade 53-2091 wireway WIREWAY,OMNITT Wireway drawer connect board Installation Procedure Table A-1. TT Part List OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D © 2010 Omnicell, Inc.
  • Page 39 Manual Override Cable 94-6182 (cable to assembly) screw SCREW,TRUSS,HD,TORX,6-32,X 1/8,SS Manual Override Cable no part # LAN cable LAN cable (external vendor source?) Electronics Tray Table A-1. TT Part List © 2010 Omnicell, Inc. OmniTT/AnesthesiaTT Installation and Service Guide/67-2024 Rev D...
  • Page 40 Feedback Form This document is designed to provide relevant technical information to those responsible for the implementation, service, and support of Omnicell products. The Documentation team needs your input, so we can continue to improve our publications. Please send us your feedback: Did this document meet your needs? If so, please let us know what we’re doing right.
