OmniCell OmniRx Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

OmniRx Service Guide
67-2023 Rev D

Advertisement

Table of Contents
loading

Related Manuals for OmniCell OmniRx

Summary of Contents for OmniCell OmniRx

  • Page 1 OmniRx Service Guide 67-2023 Rev D...
  • Page 2 This guide and accompanying software and/or hardware described in it are protected under copyright laws and may not be copied, wholly or in part, without the express written consent of Omnicell, Inc. The same proprietary and copyright notices must be attached to any permitted copies as were attached to the original documents.

  • Page 3: Table Of Contents

    ..............Index-1 © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 4 ..........Feedback-1 OmniRx Service Guide/67-2023 Rev D...

  • Page 5: Electronics Sled

    2. Unplug the power cable to the OmniRx. 3. Unlock the console with the #2036 key. 4. Lift the console from the rear of the OmniRx, then prop it up. Caution: Use an ESD wrist band while working inside the sled.

  • Page 6: Lcd Screen Removal

    5. Tilt the LCD assembly forward and disconnect the cables from the back of the LCD assembly. a. Disconnect the inverter to power cable. b. Disconnect the flat panel cable. 6. Remove the LCD assembly from the LCD housing. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 7: Speaker Removal

    Figure 1-4. Disconnect the speaker cable from the motherboard 3. Remove the two screws that hold the speaker in place using a Torx T10 screwdriver. Figure 1-5. Remove the speaker 4. Disconnect the speaker from the console top. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 8: Printer Removal

    Figure 1-6. Open the printer cover 3. Remove the paper from the printer. 4. Push the platen lever to the left to the disengaged position. Figure 1-7. Turn the platen lever OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 9 Figure 1-8. Remove the printer assembly screws 6. Remove the printer assembly. 7. Remove the four screws that secure the lower assembly to the frame. Figure 1-9. Remove the lower assembly screws © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 10 8. Disconnect the printer ribbon cable and the printer data cables from the printer PC Board. Figure 1-10. Remove the printer cables 9. Remove the printer. Figure 1-11. Remove the printer OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 11: Aps Printer

    1. Open the printer cover by pushing the black release mechanism toward the rear of the machine and lifting the cover. Figure 1-13. Open the printer cover 2. Remove the paper from the printer. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 12 4. Remove the four screws (two on each side) that secure the printer assembly to the cover. Figure 1-15. Remove the Screws Securing the Printer Assembly 5. Remove the printer assembly. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 13 Figure 1-16. Remove the lower assembly screws (top screws partially hidden) 7. Disconnect the four printer cables from the printer PC Board. Figure 1-17. Remove the printer cables: (a) ribbon cable (b) 2 data cables power cable) © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 14: Keyboard Service

    10. Lift the card off the frame slightly, then remove the printer ribbon cable. Keyboard Service 1. Disconnect all console cables. 2. Remove the console and set it upside down in a work area. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 15: Ps/2 Keyboard

    Figure 1-20. Remove the nuts that secure the keyboard cover to the tray 2. Remove the keyboard cover. Figure 1-21. Remove the keyboard cover 3. Remove the keyboard from the tray. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 16 8. Replace the keyboard cover. 9. Replace the screws that secure the keyboard cover to the tray. 10. Set the console back in place, then prop it up. 11. Re-connect all the cables. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 17: Usb Keyboard

    Re-assemble the parts into the bracket. 4. Attach the bracket back on the console. 5. Attach the cables. 6. Set the console back in place, then prop it up. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 18: Pc Tray Upgrade

    1. Disconnect the LAN cable and the AUX cables from the rear of the electronics sled. Figure 1-25. Location and labels for LAN and AUX cable connections on CT PC tray OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 19 Fan power cable (if applicable) Printer cable (free cable from any clips) j. Cabinet power/comm cable k. wireway cable Figure 1-26. Location of cables on the CT PC tray with PowerCom2 board © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 20: Powercom3 Tray

    1. Place the PowerCom3 tray into position inside the electronics sled. 2. Turn the two 1/4-turn fasteners securing the electronics tray clockwise to lock the tray into place. Figure 1-28. Place the CT PC tray into the OmniRx OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 21 Figure 1-30. Connect the printer cable to J27 of the motherboard Note: Ensure that the red wire is connected closest to Pin 1. 5. Connect the fan power cable to J17 on the UPS board (if applicable). © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 22 Figure 1-31. Connect the speaker cable to J45 of the motherboard 7. Connect the keyboard cable to port J42 on the motherboard. Figure 1-32. Connect the keyboard cable to J42 of the motherboard OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 23 Figure 1-33. Connect the touch screen data cable to J2 of the motherboard 9. Connect the inverter cable (backlight) to J32 on the motherboard. Figure 1-34. Connect the backlight cable to J32 of the motherboard © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 24 Insert card reader power cable pins into the disk drive power connector. d. Align the red-stripe pin to the red cable and the gray-stripe pin to the gray cable in next spot. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 25: Standardization Changes

    Electronics Sled 1-21 Standardization Changes Standardization Changes To standardize the peripherals that Omnicell products use, the Seiko printer and PS/2 keyboards are being replaced by APS printers and USB keyboards with a numeric pad. The console swapped out in this procedure.
  • Page 26 1-22 Electronics Sled Final Steps OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 27: Frames And Wireways

    Frames and Wireways Wireway Removal Important: A Pharmacist must be present when servicing drawers where medications are present. 1. Perform a graceful shutdown of the OmniRx. Refer to “General Shutdown” on page 1-1. 2. Unlock the two locks on the manual override cover with the #2202, 2232 keys.
  • Page 28 Figure 2-2. Remove the drawer rails 6. Remove the two screws on the front of the frame that help secure the wireway. Figure 2-3. Remove the two wireway screws on the front of the OmniRx OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 29 Figure 2-4. Remove the wireway screws on the side of the OmniRx 8. Pull the wireway far enough from the frame to access the SPC board connectors. 9. Disconnect the cables on top and bottom that connect the SPC board to the wireway.

  • Page 30: Manual Override Cable Service

    Manual Override Cable Service Removal 1. Perform a graceful shutdown of the electronics sled. 2. Remove the manual override cover. 3. Remove all three drawers from the OmniRx. See “Pharmacy Drawer Removal” on page 3-8. 4. Open the printer cover.
  • Page 31 Figure 2-7. Remove the two screws that secure the manual override cable to the frame 12. Remove the red handle on the front of the manual override cable. Figure 2-8. Remove the red handle on the manual override cable © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 32 Figure 2-9. Remove the nut that secures the manual override cable to the frame. 14. Remove the screw that secures the manual override cable to the manual override assembly. Figure 2-10. Remove the screw that secures the manual override cable to the frame OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 33: Replacement

    3. Place the manual override cable into the frame anchor so that the two screws are on opposite side of the anchor bracket. 4. Tighten the screws. 5. Feed the front of the manual override cable through the hole on the front of the OmniRx cabinet. 6. Replace the nut that secures the cable to the frame.
  • Page 34 2-8 Frames and Wireways Manual Override Cable Service OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 35: Drawers

    These drawers are used to contain controlled substances. Omnicell locking lid drawers provide the highest security. Users can only access one bin at a time which contains the pre-selected medication. All other bin lids remain locked. Special censors generate audible and visual feedback if entry is attempted into bins that are not pre-selected.

  • Page 36: Matrix Drawers

    3. Add the dividers to the bin liner. The dividers should snap into the bottom of the drawer and the sides of each bin liner quadrant. 4. Use the gray circular labels provided with the kit to cover any un-used divider slots in the bin liner. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 37: Lit Matrix Drawers

    (OMD4) is the same a regular double deep drawer. The OMD4 can replace an existing double deep drawer or it would replace two single deep drawers. 1. Perform a graceful shutdown of the electronic sled. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 38: Matrix Drawers Labels

    The bottom of the bin liner on any matrix drawer is numbered according to its type (i.e. 1-96, 1- 24, 1-4). These numbers are used to identify bin locations for the drawer. The drawer will be numbered by using the lowest number in a specific bin. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 39: Supply Drawer Installation

    2. Remove the cover by pushing it to the right and lifting it off. 3. Remove any false drawer front by removing the two screws securing the false drawer front using a Torx T15 screwdriver. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 40 10. Replace the slide to the slide mounting bracket with three screws using a Torx T15 screwdriver. OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 41 Use the two screws provided with a Torx T10 screwdriver. 14. Close the drawer and replace the pharmacy manual override cover. 15. Power up the cabinet. 16. Program the drawer at the OmniSupplier in Omni Configurations. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 42: Pharmacy Drawer Removal

    5. Remove the two screws securing the drawer controller cable cover to the cable clamps using a Torx T10 screwdriver. Figure 3-8. Remove the Controller Cable Cover OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 43 7. Push the release levers on either side of the drawer up or down to release the drawer. Figure 3-10. Push the Release Levers to Release the Drawer 8. Remove the pharmacy drawer from the module. © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 44 3-10 Drawers Pharmacy Drawer Removal OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.

  • Page 45: Appendix A: Part List

    MODEL OMD4,4-BIN MATRIX DRAWER,UNLIT Matrix Drawer bin labels [comes with drawer] Matrix Drawers Labels 15-7020 false drawer front MFG,ASSY,DRAWER,FRONT,DUMMY RX2 Pharmacy Drawer Installation Table A-1. OmniRx Part List © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 46 CABLE,ASSY,USB KEYBOARD,QWERTY TO MOTHERBOARD,STD,CTPC USB Keyboard 42-1304 (printer) power cable CABLE ASSY, POWER, APS PTR, CT PC BOX APS Printer 42-1307 [keypad/keyboard] ribbon cable CABLE ASSY,NUMERIC TO KEYBD, OMNIRX/TT USB Keyboard Supply Drawer 42-2101 SPC board cable CABLE,ASSY,DRAWER,CONTROLLER TO,SPC Installation 42-7030...
  • Page 47 Installation 80-0802 speaker cable CONN,CABLE ASSY,MOLDED PLUG,3.5MM STEREO,SHL'D,PVC,36IN Speaker Removal 82-6061 jumper JUMPER,SHUNT,0.1",15AU,RED Standardization Changes 91-7040 drawer slide SLIDE,OUTER HALF, DRAWER,RX,ACCURIDE C3834-156-1 [right side] Wireway Removal Table A-1. OmniRx Part List © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...
  • Page 48 Cable Service PowerCom2 Tray 94-6170 (electronics sled) fastener STUD,1/4,TURN,WING,HD,SOUTHCO 94-6173 (PC card) screw SCREW,SHCS,4-40,X,3/16,SS Seiko Printer APS Printer 95-6015 paper PAPER,THERMAL,92M ROLL,80MM WIDE Seiko Printer APS Printer Table A-1. OmniRx Part List OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 49 USB printer 1-13 keyboard 1-10 wireway 2-1 labels 3-4 LAN cable 1-14 LCD screen 1-2 locking lid drawers 3-1 manual override assembly 2-6 manual override cable 2-4 manual override cover 2-1, 3-5, 3-8 © 2010 Omnicell, Inc. OmniRx Service Guide/67-2023 Rev D...

  • Page 50: In-2 Index

    IN-2 Index OmniRx Service Guide/67-2023 Rev D © 2010 Omnicell, Inc.
  • Page 51 Documentation Feedback This document is designed to provide relevant technical information to those responsible for the implementation, service, and support of Omnicell products. The Documentation team needs your input, so we can continue to improve our publications. Sending Comments to the Technical Documentation Team Did this document meet your needs? If so, please let us know what we’re doing right.
