- Page 1 HEAT PUMP CLOTHES DRYER DH9060FS INSTALLATION GUIDE NZ AU BI EU...
-
Page 2: Safety And Warnings
• If you are using an extension cord or a portable electrical outlet device (eg HEAT PUMP CLOTHES DRYER DH9060FS multi-socket outlet box), ensure that it is positioned so that it does not come into USER GUIDE contact with water or moisture. -
Page 3: Product Dimensions
PRODUCT DIMENSIONS FRONT PROFILE PRODUCT DIMENSIONS A Overall height* B Overall width C Overall depth** D Depth with door open 1080 * Exact height is dependent on foot adjustment ** Including dial and door (when closed) Actual product dimensions may vary by ± 2 mm. PLAN... - Page 4 CAVITY & CLEARANCE DIMENSIONS * Front panel of the product ISOMETRIC FRONT PROFILE CAVITY DIMENSIONS CLEARANCE DIMENSIONS A Minimum cavity height A Minimum dryer door clearance to adjacent wall B Minimum cavity width B Minimum gap clearance to adjacent product or cabinetry* * Applies to sides, top and rear C Minimum cavity depth Flush with front panel of the product*...
- Page 5 ELECTRICAL & PLUMBING CONNECTION CONNECTION LOCATIONS / LENGTHS STANDARD INSTALL WITH WASHER Water Supply Power Supply Drain Hose Drain Hose Power Cord 1300mm 1500mm Water Hose 650mm or 1500mm WASHER DRYER The above image depicts the standard installation with a matching washer, for all other installation options please refer to fisherpaykel.com SPECIFICATIONS ELECTRICAL...
-
Page 6: Installation Options
UNPACKING INSTALLATION OPTIONS Installation location Do not install your dryer in such a way that the dryer door cannot be opened fully. Do not install the dryer outside, in a damp place, where there is a risk of freezing, where it may be rained on, in direct sunlight or close to a source of heat. -
Page 7: Water Supply
WATER SUPPLY DRAINING Water supply requirements The dryer is equipped with a condenser unit which accumulates water during the drying cycle. This water is either collected in the removable water tank located at the top left of the dryer, Your cold water should not exceed 35°C. Temperatures above this may cause damage to or you can setup your dryer to drain automatically using the drain hose provided. -
Page 8: Levelling The Dryer
DRAINING LEVELLING THE DRYER The drain hose must be secured in a drain to prevent water draining onto the floor. Ensure It is IMPORTANT to level the dryer to ensure the machine runs efficiently with minimal noise. The the drain hose is securely fixed in place to an appropriate drain and is leak-free at the dryer should be levelled in as close to its final position as possible so it stands balanced evenly connection to the machine. -
Page 9: Complete Installation
COMPLETE INSTALLATION TO BE COMPLETED BY THE INSTALLER Turn on the water and check all hose connections for leaks. Make sure there are no kinks in the hose(s). Check the hose connections for leaks again after 24 hours. Uncoil power cord, remove and discard the plastic pin cover, and plug into wall socket. …... -
Page 10: Spare Parts
SPARE PARTS SPARE PARTS* PART NO. Hose(s) inlet long (2 m) 422680P Drain hose extension (not suitable for attaching to a spigot) 425627P Hose(s) inlet large bore 426123P * Available from your Fisher & Paykel dealer or a Fisher & Paykel trained and supported service technician Complete and keep for safe reference: Model Serial no. - Page 12 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2020. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
