INFO Key
Info - Press the INFO key while in Bird's Eye, Chart or Combo View to
display information about objects that are nearest to an active cursor.
If the cursor is not active, the following menu will be displayed.
Use the 4-WAY Cursor key to select Nearest Port, Nearest Tide
Station or Nearest Current Station, then use the RIGHT Cursor
key to display the requested information.
NOTE: The built-in UniMap™ does not contain Port, Tide or Current
information. This information is only available from optional
purchase MMC/SD cards.
MENU Key
The MENU key is used to access the menu system.
Start-Up Options Menu - Press the MENU key during the power up sequence to view the
Start-Up Options menu.
X-Press
TM
Menu - Press the MENU key once for the X-Press
allows you to access frequently-used settings without having to navigate through the
whole menu system. When the X-Press
DOWN Cursor keys to move to a particular menu choice. As soon as you alter a
parameter (using the RIGHT or LEFT Cursor keys) the X-Press
temporarily, and the screen will update if it is affected by your menu setting change,
allowing you to see the effects of your action immediately. Reactivate the X-Press
Menu by using the UP or DOWN Cursor keys.
Main Menu - Press the MENU key twice for the tabbed Main Menu System. The Main
Menu System is organized under tabbed headings to help you find a specific menu item
quickly: Alarms, Sonar, Navigation, Chart, Setup, Views and Accessories tabs are part of
your tabbed Main Menu System. Use the LEFT or RIGHT 4-WAY Cursor Control key to
select a tab; then use the DOWN or UP key to select the menu item, and the LEFT or
RIGHT key to alter a menu setting.
3:21 AM
Page 42
TM
Menu. The X-Press
TM
menu
TM
menu is displayed, you can use the UP or
TM
menu will collapse
TM
35
4-WAY Cursor Control Key
The 4-Way Cursor Control Key has multiple functions, depending on the
situation:
• Use the DOWN or UP arrow keys to select a menu choice from the menu list,
then use the LEFT or RIGHT arrow keys to change a menu setting.
NOTE: Menu choices are implemented and saved immediately - no further action is required.
• In all Sonar views but the Big Digits view, pressing any 4-WAY Cursor Control key
will activate Freeze Frame and will then allow you to position the cursor on the
display.
MARK Key
Press the MARK key while in any view to mark the position of a waypoint,
either at the current boat location, or, if the Cursor is active, at the current
Cursor location.
The MARK key only functions if you have the GPS receiver connected, or if you have
enabled Screen Snapshot from the Accessories menu tab. If you have enabled the Screen
Snapshot feature, pressing the MARK key still creates a waypoint, but it also captures the
screen image to the optional-purchase MMC/SD card.
NOTE: You must have an optional-purchase MMC/SD card installed for the screen
snapshot feature to work.
Navigation is not affected by the Screen Snapshot feature. Also, if Screen Snapshot is
enabled but there is no GPS receiver connected, pressing the MARK key will capture the
screen image and display an error saying that a GPS position fix is required to create a
waypoint.
GOTO Key
If the Cursor is active, pressing the GOTO key while in any view creates a
waypoint and starts navigation towards that waypoint. If the Cursor is
not active, pressing the GOTO key displays the list of waypoints, so that
you can select the waypoint towards which you want to navigate.
36
