- Page 1 INadf002V02_UK A91-054 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
- Page 2 18 24 UMBER ESCRIPTION Upright Main beam Front upright Cross beam Front Stabilizer Pivot Bar Cross bar Leg extension bracket Fly arm Foam tube Foam tube Fix locking Spring locking Seat Backrest End cap End cap End cap End cap End cap...
- Page 3 Protect cap Protect cap Foam “U” Rear stabilizer Knob Knob Screw 8 x 50 mm Screw 10 x 60 mm Screw 10 x 60 mm Screw 8 x 40 mm Screw 8 x 20 mm Screw 10 x 120 mm Screw 8 x 45 mm Washer 8 x 16 x 1,5 mm...
- Page 4 Insert the cross bar (7) to the hole of the two uprights (1), STEP 2 attach the pivot bar (6) to the main beam (2), fi x the backrest (15) on the pivot bar (6) use 4 sets of screw (32) and washer (36), then fi x the seat (14) on the main beam (2) use 4 sets of screw (33) and washer (36), insert the foam tube (26) to the front upright (3) and attach the foam (27) to the foam tube (26).
