Installing the Stainless Steel Handles

This appliance includes two stainless steel handles
that are not required to operate the unit. To install the
handles, follow the instructions below:
1. Remove the door gasket.
2. Install the handle with the screws provided. (DO
NOT over-tighten as this will cause damage to the
stainless steel door surface.)
3. Replace the door gasket.
Full Panel Overlay Installation Instructions
These models are designed for field-installed overlay
panels. The overlay panels cover the stainless steel to
give a built-in appearance. The overlay panel and
appropriate hardware are not included with the unit
and the end user needs to prepare them himself.
Please follow the instructions below for installation:
Remove any items stored inside the drawers.
Press the left slide release lever down and at the
same time lift the corresponding right slide lever
up, and pull the drawer out until it is free of tracks
and the cabinet. (Fig. 1)
Peel off the gasket and remove the handle by
removing the two screws that attach the handle to
the door.
Drill the 2 holes shown by using a 3/16" drill bit on
the bottom of drawer door front. (Fig. 2)
Cut the overlay panels with thickness 3/4" to the
following dimensions: 23.15" x 14.92".
If reusing the handles that came with the unit, drill
two holes with diameter 3/16" in the overlay panel.
Attach the handle and overlay panel together to
the drawer face using 2 M4x55 screws and
through the upper 2 existing holes inside the door
groove. Then attach the overlay panel to the
drawer face using 2 wood screws #10x1.5
(ST4x40) Type AB Phillips and through the lower 2
existing holes inside the door groove. (Fig. 3)
If user-supplied handles will be used, attach the
handles to the overlay panels by using the flat
head screws and drive the screws flush with the
panels. Then attach the overlay panel to the
drawer face using the 4 wood screws #10x1.5
(ST4x40) and through the 4 existing holes inside
the door groove.
Peel back the gaskets, then align the left and right slide channels with the tracks in the cabinet.
Ensuring an even track engagement on both sides, gently push the drawer into the cabinet until
it stops.
