Overview of All Actions
Action
Event In- Address Location
struc-
tion
R1 TR T
<time>
R1 TLC T
<time>
R1 TDC T
<time>
R1 TRC T
<time>
13-22
X As soon as a registration is set, the timer stops.
Timer bit (status of the timer) and timer value are
reset to 0.
X As soon as a registration is set and the condition
(interlock) is satisfied, the timer starts. For the
specified time, the timer bit (status of the timer) is
set to 1, when the time elapses, it is reset to 0.
X As soon as a registration is set and the condition
(interlock) is satisfied, the timer starts. For the
specified time, the timer bit (status of the timer) is
set to 0, when the time elapses, it is set to 1.
X As soon as a registration is set and the condition
(interlock) is satisfied, the timer stops. Timer bit
(status of the timer) and timer value are reset to 0.
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
Explanation
C79000-G7076-C526-01
Address
range
x = no.
of timer
x = no.
of timer
x = no.
of timer
x = no.
of timer
