  • Page 2 ___________________ Digital output module Preface DQ 16x24...48VUC/125VDC/0.5A ST ___________________ Documentation guide (6ES7522-5EH00-0AB0) ___________________ SIMATIC Product overview ___________________ Wiring S7-1500/ET 200MP Digital output module ___________________ DQ 16x24...48VUC/125VDC/0.5A ST Parameters/address space (6ES7522-5EH00-0AB0) ___________________ Interrupts/diagnostics alarms Manual ___________________ Technical specifications ___________________ Dimensional drawing...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 4: Preface

    Siemens recommends strongly that you regularly check for product updates. For the secure operation of Siemens products and solutions, it is necessary to take suitable preventive action (e.g. cell protection concept) and integrate each component into a holistic, state-of-the-art industrial security concept.
  • Page 5 Siemens accepts no liability for the use of the open source software over and above the intended program sequence, or for any faults caused by modifications to the software.

  • Page 6: Table Of Contents

    Table of contents Preface ..............................4 Documentation guide ..........................7 Product overview ..........................10 Properties ..........................10 Wiring ..............................12 Parameters/address space ........................14 Parameters ..........................14 Description of parameters ...................... 14 Address space ........................15 Interrupts/diagnostics alarms......................... 20 Status and error displays ....................... 20 Interrupts ..........................

  • Page 7: Documentation Guide

    This arrangement enables you to access the specific content you require. Basic information The System Manual and Getting Started describe in detail the configuration, installation, wiring and commissioning of the SIMATIC S7-1500 and ET 200MP systems. The STEP 7 online help supports you in the configuration and programming. Device information Product manuals contain a compact description of the module-specific information, such as properties, wiring diagrams, characteristics and technical specifications.
  • Page 8 (https://support.industry.siemens.com/cs/us/en/view/68052815). Manual Collection S7-1500/ET 200MP The Manual Collection contains the complete documentation on the SIMATIC S7-1500 automation system and the ET 200MP distributed I/O system gathered together in one file. You can find the Manual Collection on the Internet (http://support.automation.siemens.com/WW/view/en/86140384).
  • Page 9 ● Manuals, characteristics, operating manuals, certificates ● Product master data You can find "mySupport" - CAx data on the Internet (http://support.industry.siemens.com/my/ww/en/CAxOnline). Application examples The application examples support you with various tools and examples for solving your automation tasks. Solutions are shown in interplay with multiple components in the system - separated from the focus on individual products.

  • Page 10: Product Overview

    Product overview Properties Article number 6ES7522-5EH00-0AB0 View of the module Figure 2-1 View of the module DQ 16x24...48VUC/125VDC/0.5A ST Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 11 Other components The following component must be ordered separately: Front connectors, including potential jumpers and cable ties You can find additional information on accessories in the system manual S7-1500/ET 200MP (http://support.automation.siemens.com/WW/view/en/59191792). Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...

  • Page 12: Wiring

    This section contains the block diagram of the module and outlines various connection options. You can find information on wiring the front connector, establishing a cable shield, etc. in the system manual S7-1500/ET 200MP (http://support.automation.siemens.com/WW/view/en/59191792). Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0)
  • Page 13 Wiring Block diagram and terminal assignment The example in the following figure shows the terminal assignment and channel addressing (output byte a and output byte b). Note Do not insert the potential jumpers included with the front connector! ① Backplane bus interface Channel or channel status LED (green) Status display LED (green) ERROR...

  • Page 14: Parameters/Address Space

    ● Central operation with a S7-1500 CPU ● Distributed operation on PROFINET IO in an ET 200MP system ● Distributed operation on PROFIBUS DP in an ET 200MP system For parameter assignment in the user program, the parameters are transferred to the module using the WRREC instruction (parameter assignment in RUN) and data records;...

  • Page 15: Address Space

    Parameters/address space 4.3 Address space Address space The module can be configured differently in STEP 7; see following table. Depending on the configuration, additional/different addresses are assigned in the process image of the outputs/inputs. The letters "a and b" are printed onto the module. "IB a" for example, stands for module start address input byte a.
  • Page 16 Parameters/address space 4.3 Address space Address space for configuration as 16-channel DQ 16x24...48VUC/125VDC/0.5A ST The following figure shows the assignment of the address space for the configuration as a 16-channel module with value status. You can freely assign the start address for the module. The addresses of the channels are derived from the start address.
  • Page 17 Parameters/address space 4.3 Address space Address space for configuration as 2 x 8-channel DQ 16x24...48VUC/125VDC/0.5A ST S QI For the configuration as a 2 x 8-channel module, the channels of the module are divided into multiple submodules. The submodules can be assigned to different IO controllers when the module is used in a shared device.
  • Page 18 Parameters/address space 4.3 Address space Value status (Quality Information, QI) The meaning of the value status depends on the submodule on which it occurs. For the first submodule (=basic submodule), the value status 0 indicates that the value is incorrect or that the IO controller of the basic submodule is in STOP state. For 2nd to 4th submodule (=MSO submodule), the value status 0 indicates that the value is incorrect or one of the following errors has occurred: ●...
  • Page 19 S MSO with value status Reference You can find information on the Shared Input/Output (MSI/MSO) function in the section Module-Internal Shared Input/Output (MSI/MSO) of the PROFINET with STEP 7 V13 (https://support.industry.siemens.com/cs/ww/en/view/49948856) function manual. Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...

  • Page 20: Interrupts/Diagnostics Alarms

    Interrupts/diagnostics alarms Status and error displays LED displays The following figure shows the LED displays (status and error displays) of module. Figure 5-1 LED displays of the module DQ 16x24...48VUC/125VDC/0.5A ST Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 21 Interrupts/diagnostics alarms 5.1 Status and error displays Meaning of the LED displays The tables below explain the meaning of the status and error displays. Remedial measures for diagnostics alarms can be found in section Diagnostics alarms (Page 22). RUN and ERROR LED Table 5- 1 Status and error displays RUN and ERROR Meaning...

  • Page 22: Interrupts

    Interrupts/diagnostics alarms 5.2 Interrupts Interrupts Digital output module DQ 16x24...48VUC/125VDC/0.5A ST supports diagnostic interrupts. For detailed information on the error event, refer to the diagnostic interrupt organization block with the "RALRM" instruction (read additional interrupt information) and to the STEP 7 online help.

  • Page 23: Technical Specifications

    Technical specifications Technical specifications of the DQ 16x24...125VUC/0.5A ST 6ES7522-5EH00-0AB0 General information Product type designation DQ 16x24 ... 48VUC/125VDC/0.5A ST Hardware functional status FS01 Firmware version V1.0.0 Product function I&M data Yes; I&M0 to I&M3 Engineering with STEP 7 TIA Portal can be configured/integrated V13 SP1 / - as of version STEP 7 can be configured/integrated as of version V5.5 SP3 / -...
  • Page 24 Technical specifications 6ES7522-5EH00-0AB0 Output current for signal "1" rated value 0.5 A for signal "1" permissible range, max. 0.6 A Output delay with resistive load "0" to "1", max. 5 ms "1" to "0", max. 5 ms Parallel connection of two outputs For logic operations For increased performance For redundant control of a load...
  • Page 25 230 g Note External fuse for outputs The outputs have to be protected by an external fuse. Recommendation: Siemens 2A 3NW6002-4 in fuse holder 3NW7014-4. When installed in a danger area according to the National Electric Code (NEC), the fuse must only be removed with the correct tool when the module is not in an explosion-proof zone.

  • Page 26: Dimensional Drawing

    Dimensional drawing Dimensional drawing The dimensional drawing of the module on the mounting rail, as well as a dimensional drawing with open front cover, are provided in this appendix. Always observe the specified dimensions for installations in cabinets, control rooms, etc. Figure A-1 Dimension drawing of the DQ 16x24...48VUC/125VDC/0.5A ST module Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0)
  • Page 27 Dimensional drawing A.1 Dimensional drawing Figure A-2 Dimension drawing of the DQ 16x24...48VUC/125VDC/0.5A ST module, side view with open front cover Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...

  • Page 28: Parameter Data Records

    Parameter data records Parameter assignment and structure of the parameter data records The data records of the module have an identical structure, regardless of whether you configure the module with PROFIBUS DP or PROFINET IO. Dependencies for configuration with GSD file When a GSD file is used to configure a module, dependencies can arise when "assigning the parameters".
  • Page 29 Parameter data records B.1 Parameter assignment and structure of the parameter data records Assignment of data record and channel For the configuration as a 1 x 16-channel module, the parameters are located in data records 64 to 79 and are assigned as follows: ●...

  • Page 30: Open Source Software

    License Conditions and Disclaimers for Open Source Software and other Licensed Software In the product "Digital Modules, Analog Modules, Technological Modules, Communication Modules and Power Supply Modules of the SIMATIC S7-1500, ET 200MP", Copyright Siemens AG, 2013 - 2014 (hereinafter "Product"), the following Open Source Software is used either unchanged or in a form that we have modified, and additionally the other License Software noted below.
  • Page 31 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 32 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 33 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 34 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 35 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 36 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 37 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 38 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 39 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 40 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
  • Page 41 Open Source Software C.1 Open Source Software Digital output module DQ 16x24...48VUC/125VDC/0.5A ST (6ES7522-5EH00-0AB0) Manual, 11/2015, A5E35683139-AA...
