Parameter Data
Type
S_OFF BOOL STEP
Manual mode: Deactivate the displayed step
T_PREV BOOL
PREVIOUS_TRANSITION:
Display previous valid transition in T_NO
T_NEXT BOOL
NEXT_TRANSITION:
Display next valid transition in T_NO
T_PUSH BOOL
PUSH_TRANSITION:
Transition switches when the condition is
satisfied and T_PUSH (edge)
Requirement: Inching (SW_TAP) or automatic
or step-by-step (SW_TOP) mode
If the block is Version V4 (or earlier), the first
valid transition switches. If the block is Version
V5 and if the input parameter T_NO is specified,
the transition whose number is displayed
switches. Otherwise, the first valid transition
switches.
