Overview of All Actions
Action
Event In- Address Location
struc-
tion
V1: Timers in actions linked to supervision errors entering the state
V1 TL T
<time>
V1 TD T
<time>
V1 TR T
<time>
V1 TLC T
<time>
V1 TDC T
<time>
V1 TRC T
<time>
V0: Timers in actions linked to supervision errors leaving the state
V0 TL T
<time>
13-20
X As soon as a supervision error occurs while the
step is active or a supervision error had been
detected before the step became active, the timer
starts. For the specified time, the timer bit (status of
the timer) is set to 1, when the time elapses, it is
reset to 0.
X As soon as a supervision error occurs while the
step is active or a supervision error had been
detected before the step became active, the timer
starts. For the specified time, the timer bit (status of
the timer) is set to 0, when the time elapses, it is set
to 1.
X As soon as a supervision error occurs while the
step is active or a supervision error had been
detected before the step became active, the timer
stops. Timer bit (status of the timer) and timer value
are reset to 0.
X As soon as a supervision error occurs while the
step is active or a supervision error had been
detected before the step became active and the
condition (interlock) is satisfied, the timer starts. For
the specified time, the timer bit (status of the timer)
is set to 1, when the time elapses, it is reset to 0.
X As soon as a supervision error occurs while the
step is active or a supervision error had been
detected before the step became active and the
condition (interlock) is satisfied, the timer starts. For
the specified time, the timer bit (status of the timer)
is set to 0, when the time elapses, it is set to 1.
X As soon as a supervision error occurs while the
step is active or a supervision error had been
detected before the step became active and the
condition (interlock) is satisfied, the timer stops.
Timer bit (status of the timer) and timer value are
reset to 0.
X As soon as a supervision error leaves the state (is
eliminated or acknowledged), the timer starts. For
the specified time, the timer bit (status of the timer)
is set to 1, when the time elapses, it is reset to 0.
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
Explanation
C79000-G7076-C526-01
Address
range
x = no.
of timer
x = no.
of timer
x = no.
of timer
x = no.
of timer
x = no.
of timer
x = no.
of timer
x = no.
of timer
