Overview of All Actions
Event Instruction
V0 ON
V0 OFF
L0: Actions linked with interlocks entering the state
L0 N
L0 S
L0 R
L0 CALL
L0 ON
L0 OFF
13-8
Action
Address Location
Area
S i
S i
Q,I,M,D* m.n
Q,I,M,D* m.n
Q,I,M,D* m.n
FB, FC, Block
SFB, SFC number
S i
S i
S7-GRAPH for S7 300/400 Programming Sequential Control Systems
Explanation
As soon as a supervision
error leaves the state (is
eliminated or acknowledged),
step i is activated.
As soon as a supervision
error leaves the state (is
eliminated or acknowledged),
step i is also deactivated.
As soon as the interlock
condition is satisfied (enters
state) when the step is active,
the signal state of the address
is 1.
As soon as the interlock
condition is satisfied when the
step is active (enters state),
the address is set to 1 and
then remains set to 1.
As soon as the interlock
condition is satisfied when the
step is active (enters state),
the address is set to 0 and
then remains set to 0.
As soon as the interlock
condition is satisfied when the
step is active (enters state),
the specified block is called.
As soon as the interlock
condition is satisfied when the
step is active (enters state),
step i is activated.
As soon as the interlock
condition is satisfied when the
step is active (enters state),
step i is deactivated.
C79000-G7076-C526-01
Address
range
i = step
number
i = step
number
0.0 to
65535.7
0.0 to
65535.7
0.0 to
65535.7
i = step
number
i = step
number
