V1: Counters in actions linked to supervision errors entering the state
V1
CS
C
<initial
counter
value>
V1
CU
C
V1
CD
C
V1
CR
C
V1
CSC
C
<initial
counter
value>
V1
CUC
C
V1
CDC
C
V1
CRC
C
S7-GRAPH for S7-300/400 Programming Sequential Control Systems
C79000-G7076-C526-01
Location
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active,
the initial counter value is loaded in the
counter.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active,
the counter is incremented by 1.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active,
the counter is decremented by 1.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active,
the counter is reset to 0.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active
and the condition (interlock) is satisfied, the
initial counter value is loaded in the counter.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active
and the condition (interlock) is satisfied, the
counter is incremented by 1.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active
and the condition (interlock) is satisfied, the
counter is decremented by 1.
X
As soon as a supervision error occurs while
the step is active or a supervision error had
been detected before the step became active
and the condition (interlock) is satisfied, the
counter is reset to 0.
Overview of All Actions
Explanation
Address
range
x = counter
number
x = counter
number
x = counter
number
x = counter
number
x = counter
number
x = counter
number
x = counter
number
x = counter
number
13-15
